8.10.8. Save analog color properties
Description: Save analog color properties of the input ports.
Command {:PICTURE#<in>@<S/A>I=SAVE)
Response
Legend:
8.10.9. Query analog color properties
Description: Check analog color properties data of the input ports.
Command {:PICTURE#<in>@<S/A>I=?}
Response
Legend:
8.10.10. Reset analog color properties
Description: Reset analog color properties of the input ports.
Command {:PICTURE#<in>@<S/A>I=FACTORY}
Response
Legend:
8.10.11. Set analog input audio parameters
Description: This command changes the setup of the ADC on the audio board.
Command {:ADC#<in>@<S/A>I=<GAIN>}
Response (ADC#<in>@<S/A>I=<GAIN)CrLf ← (ADC#1@SI=9;)CrLf
Legend:
Section 8. Programmers reference
Format
(P●SAVED)CrLf
(PICTURE#<in>@<S/A>I=
<DF_CHA>;<DF_CHB>;<DF_CHC>;
<G_CHA>;<G_CHB>;<G_CHC>;
<O_CHA>;<O_CHB>;<O_CHC>;
<CONT>;<SAT>;<BRIGHT>;<HUE>;)CrLf
Please read section 8.10.7.
Format
(PICTURE#<in>@<S/A>I=
<DF_CHA>;<DF_CHB>;<DF_CHC>;
<G_CHA>;<G_CHB>;<G_CHC>;
<O_CHA>;<O_CHB>;<O_CHC>;
<CONT>;<SAT>;<BRIGHT>;<HUE>;)CrLf
Please read section 8.10.7.
Format
(P●SAVED)CrLf
(PICTURE#<in>@<S/A>I=
<DF_CHA>;<DF_CHB>;<DF_CHC>;
<G_CHA>;<G_CHB>;<G_CHC>;
<O_CHA>;<O_CHB>;<O_CHC>;
<CONT>;<SAT>;<BRIGHT>;<HUE>;)CrLf
Please read section 8.10.7.
Format
<S/A>:
Affected ports:
S = single selected output
A = all outputs
<GAIN>:
Gain on the input port: (default value: 0)
0, 3, 6, 9, 12, 15, 18, 21, 24 dB
→ {:picture#3@si=save}
←
(P SAVED)CrLf
←
(PICTURE#3@SI=
1023;1023;1023;
1023;1023;1023;
1023;1023;1023;
128;128;0;0;)CrLf
(Set analog color
properties)
→ {:picture#3@si=?}
← (PICTURE#3@SI=
1023;1023;1023;
1023;1023;1023;
1023;1023;1023;
128;128;0;0;)CrLf
(Set analog color
properties)
→ {:picture#3@si=factory}
←
(P SAVED)CrLf
←
(PICTURE#3@SI=
1023;1023;1023;
1023;1023;1023;
1023;1023;1023;
128;128;0;0;)CrLf
(Set analog color
properties)
→ {:adc#1@si=9}
UMX4x4-Pro2
User's Manual
Example
Example
Example
Example
Page 107 / 136
