9. Commands – Quick summary
Status and identification commands
View product type
View serial number
View Firmware version of the CPU
View CPU firmware compile time
View installed controllers' firmware
View current control protocol
Set current control protocol
View crosspoint size
View LAN versions
View router's health
View installed I/O boards
View error list
System commands
Reload factory defaults
Count HDCP keys
Clear HDCP key cache
Restart matrix router
Communication setup commands
Query IP settings
Reload factory default IP settings
Enable DHCP IP setting
Query RS-232 baud rate
Change RS-232 baud rate
EDID router commands
Change EDID on input
Change EDID on all inputs
Save EDID to user memory (Learn EDID)
View emulated EDIDs on all inputs
Watch EDID validity table
View EDID header
Download EDID content from the router
Upload EDID content to the router
Delete EDID from memory
View emulated EDIDs type
Page 116 / 136
Section Command
8.4.1 {I}
8.4.2
{S}
8.4.3 {F}
8.4.4 {CT}
8.4.5
{FC}
8.4.6 {P_?}
8.4.7 {P_x}
8.4.8 {GETSIZE}
8.4.9 {LAN_VER=?}
8.4.10
{ST}
8.4.11 {IS}
8.4.12 {ELIST=?}
Section Command
{FACTORY=<f1>;<f2>;...;<fx>}
8.5.1
8.5.2 {:HDCPTEST<in>@<num>}
8.5.3 {:HDCPRESET}
8.5.4
{RST}
Section Command
8.6.1 {IP_CONFIG=?}
8.6.2
{IP_CONFIG=!}
8.6.3 {IP_CONFIG=D}
8.6.4 {RS232BAUD=?}
8.6.5
{RS232BAUD=<rate>}
Section Command
8.7.1 {Exx:<loc2>}
8.7.2 {EA:<loc2>}
8.7.3 {Uxx:<loc2>}
8.7.4 {VEDID}
8.7.5 {WV<type>}
8.7.6 {WH<loc>}
8.7.7 {WE<loc>}
8.7.8 {WL#<loc>}
{WB#<n>●<Bn0>●<Bn1>●<Bn2>●<Bn3>●<Bn4>
●<Bn5>●<Bn6>●<Bn7>}
8.7.9 {DE<loc>}
8.7.10 {WITE}
Section 9. Commands – Quick summary
