Input settings
Set input port properties
Query input port properties
Reload factory defaults of input port
properties
Set analog timing properties
Query analog timing properties
Reset analog timing properties
Set analog color properties
Save analog color properties
Query analog color properties
Reset analog color properties
Set analog input audio parameters
Query analog input audio properties
Reset analog input audio properties
Set the color of 'no sync' picture
Query the color of 'no sync' picture
Reset the status and the color of 'no sync'
Query timings of the incoming signal
Output settings
Set output video properties
Query output video properties
Reset output video properties
Set output audio properties
Query output audio properties
Reset analog output audio properties
Page 118 / 136
Section Command
8.10.1 {:DVII#<in>@<S/A>I=<VIDEO>;<X>;
<AUDIO>;<HDCP>}
8.10.2 {:DVII#<in>@<S/A>I=?}
8.10.3
{:DVII#<in>@<S/A>I=FACTORY}
8.10.4 {:ANALOG#<in>@<S/A>I=<PHS>;<FHS>;<HS>;
<VS>;<HP>;<VP>;}
8.10.5 {:ANALOG#<in>@<S/A>I=?}
8.10.6 {:ANALOG#<in>@<S/A>I=RESET}
8.10.7
{:PICTURE#<in>@<S/A>I=
<DF_CHA>;<DF_CHB>;<DF_CHC>;
<G_CHA>;<G_CHB>;<G_CHC>;
<O_CHA>;<O_CHB>;<O_CHC>;
<CONT>;<SAT>;<BRIGHT>;<HUE>;}
8.10.8 {:PICTURE#<in>@<S/A>I=SAVE}
8.10.9 {:PICTURE#<in>@<S/A>I=?}
8.10.10 {:PICTURE#<in>@<S/A>I=FACTORY}
8.10.11 {:ADC#<in>@<S/A>I=<GAIN>}
8.10.12
{:ADC#<in>@<S/A>I=?}
8.10.13 {:ADC#<in>@<S/A>I=FACTORY}
8.10.14 {SETBG=<EN>;<RED>;<GREEN>;<BLUE>;}
8.10.15 {SETBG=?}
8.10.16 {SETBG=FACTORY}
8.10.17 {GETTIMINGS#<in>@<S/A>=?}
Section Command
8.11.1 {:HDMI#<out>@<S/A>O=<MODE>;<CSPAC>;
<CRANG>;<SUBS>;<HDCP>;}
8.11.2 {:HDMI#<out>@<S/A>O=?}
8.11.3 {:HDMI#<out>@<S/A>O=FACTORY}
8.11.4
{:AUDIO#<out>@<S/A>O=<RVOL>;<LVOL>;}
8.11.5 {:AUDIO#<out>@<S/A>O=?}
8.11.6 {:AUDIO#<out>@<S/A>O=FACTORY}
Section 9. Commands – Quick summary
