5.4.

Front panel LCD menu operation

5.4.1. Basic concept

There are three operating modes of the LCD menu:
Normal mode
EDID mode
Signal present mode

5.4.2. Menu structure

Page 36 / 136
Most settings can be done in this mode. It is active when
neither the EDID nor the SIGNAL PRESENT button lights.
Use this mode to set up the emulated EDID on the inputs, learn
EDID form the outputs or to view the EDID memory. Enter or
exit this mode by pressing the EDID button. The illuminated
button shows that this mode is active.
This mode is for checking the presence of the display devices
and incoming signals. Enter or exit this mode by pressing the
SIGNAL PRESENT button. The illuminated button shows that
this mode is active.
Normal mode
Default display
IP settings...
IP address
IP Port
Save & exit
Exit & no save
Power status
Firmware versions
RS-232 settings
View log...
1/n Notice
2/n Notice
...
n/n Notice
Factory reset
IP reset
IO card reset
EDID reset
HDCP key reset
Return
Input settings
Interface
Audio
HDCP enabled
Analog video....
Analog audio....
Remote input control...
Return
Output settings
Mode
Analog audio.....
HDCP
RICOD slave
Return
HDCP keycounter
EDID mode
View EDID
Factory EDIDs
User EDIDs
Dynamic EDIDs
Emulated EDIDs
Save EDID
Switch EDID
Signal present mode
Section 5. Operation
