Info: The LCD menu shows always 8 input ports to control irrespectively of the remote
controlled device.
Info: All the four cases will take effect only if the remote controlled device is able to perform the
switching command. (e.g. If the remote controlled device is not able to mute its output
port the mute command will be ignored.)
7) Navigate to the 'Return' item then press the ENTER 
Output settings
Navigate to this menu in the main menu list.
Select the output port
Use the up ▲ and down ▼ buttons to select the port that
needs adjustment and then press the ENTER  button.
Output port settings submenu
Use the left ◄ and right ► buttons to select the parameter to be changed. Use the up ▲
and down ▼ buttons to change the value.
1) Mode: The 'Mode' can be set to Auto, DVI, HDMI. The
2) Analog audio....: The 'Analog audio....' submenu contains
3) The 'HDCP' option sets the HDCP encryption on the output. The Auto setting applies
4) Use the left ◄ and right ► buttons to select the 'RICOD
Changes take effect immediately, don't need to press the ENTER
Info:
5) Return: Navigate to the 'Return' item then press the ENTER  button to step back to
Section 5. Operation
Select the 'Return' to step back to the "Input settings"
submenu.
button to step back to the main menu.
'Auto' option sets the signal mode regarding to the
attached display device's EDID and the incoming signal. Use the up ▲ and down ▼
buttons to change the value.
the attributes of the analog audio signal which is
connected to the input port. Use the left ◄ and right ►
buttons to select the parameter to be changed. Use the
up ▲ and down ▼ buttons to change the value.
a. Volume: from 0 dB to -78 dB
b. Balance: from 0% to 100%
c. Return
Navigate to the 'Output 1 Return' item then press the
ENTER  button to step back to the output port
settings
encryption when the incoming signal is encrypted. The Always setting forces
encryption on any incoming video signal. Use the up ▲
and down ▼ buttons to change the value.
slave' settings. Use the up ▲ and down ▼ buttons to change the value. It can be:
a. 'Enabled': The local device is able to receive RICOD commands over its
output port. (Slave mode is enabled on the selected output port.)
b. 'Disabled': The local device is not able to receive
RICOD commands on its output port. (Slave
mode is disabled on the selected output port.)
the out port settings.
UMX4x4-Pro2
User's Manual
Input 1
Return
Return
Output settings
Output #
Output #
Mode: Auto
Output #
Analog audio....
Output #
Volume:-0dB
Output #
Return
Output #
HDCP:Auto
Output 1
RICOD slave:Disa

button.
