8.5.4. Restart matrix router

Description: The matrix router can be restarted without unplugging power.
Command {RST}
Response (Booting...)CrLf
Legend:
Explanation: The matrix reboots and sends a message when it is ready.
Info: The response can be seen only if the connection to the router is still alive.

8.6. Communication setup commands

8.6.1. Query IP settings

Description: IP settings can be retrieved from the router with this command.
Command {IP_CONFIG=?}
Response (IP_CONFIG=<id>
Legend:
Explanation: The router has a fix IP address 192.168.0.105 on the 255.255.255.0 subnet
with a gateway on 192.168.0.1 and communicates over TCP port: 10001.

8.6.2. Reload factory default IP settings

Description: This command sets the router to the factory default IP setup.
Command {IP_CONFIG=!}
Response (Changing●IP● configuration...)CrLf
Parameters after successful command execution:
This command can be used on all control interfaces (LAN and RS-232) but the '(DONE!)'
Info:
response cannot be seen on LAN because the connection is dropped just after the
'(Changing IP configuration...)' response.
Info: DHCP setting can be reloaded by the front panel buttons as well (see section
page 47) or on the front panel LCD menu (see section
Page 88 / 136
Format
(<name>●Ready!)CrLf
<name> is the type of the matrix
Format
●<ip_address>●<port>
●<mask>●<gateway>)CrLf
Identifier
<id> 0: fix IP
<ip_address> IP address
<port> TCP/IP port
<mask> subnet mask
<gateway> gateway address
Format
(DONE!)CrLf or
Parameter
IP address
port number
Subnet mask
Gateway
→ {rst}
←
(Booting...)CrLf
←
(UMX4x4-Pro2 Ready!)CrLf
→ {ip_config=?}
← (IP_CONFIG=0 192.168.000.105 10001
255.255.255.000 192.168.000.001)CrLf
Description
2: DHCP
→ {ip_config=!}
← (Changing IP configuration...)CrLf
← (DONE!)CrLf
(FAILED!)CrLf
192.168.254.254
10001
255.255.0.0
0.0.0.0
5.4.4
Section 8. Programmers reference
Example
Example
Default value
0
192.168.254.254
10001
255.255.0.0
0.0.0.0
Example
Value
on page 37), as well.
6.1.5 on
