8.7.9. Delete EDID from memory

Description: Clear EDID from memory location <loc>.
Command {DE<loc>}
Response (DE_OK)CrLf
Legend: Depending on <loc>, one EDID, or all EDIDs in a block can be cleared.
Explanation: All user EDIDs are cleared from memory.

8.7.10. View emulated EDIDs type

Description: Shows the type (Analog, DVI, HDMI) of the currently emulated EDIDs for
each input.
Command {WITE}
Response (WITE●<in1><in2><in3><in4>)CrLf ← (WITE DHAA)CrLf
Legend:
Explanation: DVI EDID is emulated on the input 1. HDMI EDID is emulated on the input
Page 94 / 136
Format
(E_S_C)CrLf
<loc> Result
Fxx Not valid! Factory EDID cannot be deleted. No response.
Uxx Specified User EDID is deleted.
Specified Dynamic EDID is deleted. It will be empty until a new
Dxx
monitor is connected.
Specified Emulated EDID cleared. By default F49 EDID is copied
Exx
to it.
F*
Not valid! Factory EDID cannot be deleted. No response.
U*
All User EDIDs are deleted.
All Dynamic EDIDs are deleted. They will be empty until a new
D*
monitor is connected.
All Emulated EDIDs are cleared. By default F49 EDID is copied
E*
to them.
Format
All <inx> indexes show a type (what kind of EDID is emulated to that input
port.)
2. Analog EDID is emulated on the input 3 and input 4.
Example
→ {deu*}
←
(DE_OK)CrLf
←
(E_S_C)CrLf
Example
→ {wite}
Section 8. Programmers reference
