Switching operations
Take mode
If the Autotake button is outlined with black color Take mode is active. In
Take mode any crosspoint change – (dis)connect ports to/from the
previously selected port – is executed only after pressing the Take button. Following
steps describe the process of the switching:
Step 1. Press the desired Input switch or Output switch button to select switching mode.
Step 2. Select the desired port; it will be highlighted with yellow color and also displayed
Step 3. Connected port(s) is/are highlighted with white color and also displayed on the
Step 4. Create the desired crosspoint settings by (de)selecting the ports; they will start to
Step 5. Press Take button to execute changes or Cancel to ignore the operations.
Info: Take mode remains active until it is switched off. Selecting another view mode or menu
does not change the Take/Autotake mode state.
Autotake mode
If the Autotake button is outlined with yellow color Autotake mode is
active. In this mode any crosspoint change – (dis)connect ports to/from
the previously selected port – is executed immediately after pressing the port button.
Following steps describe the process of the switching:
Step 1. Press the desired Input switch or Output switch button to select switching mode.
Step 2. Select the desired port; it will be highlighted with yellow color and also displayed
Step 3. Connected ports are highlighted with white color and also displayed on the port
Step 4. Create the desired crosspoint settings by (de)selecting the ports; the changes are
Info: Autotake mode remains active until it is switched off. Selecting another view mode or
menu does not change the Take/Autotake mode state.
Port settings
Press the desired port button on the port bar on the right.
Info: Port settings of selected port are also available by pressing the Parameters button.
Section 7. Software control –Lightware Device Controller and Web
on the port bar on the right.
port bar on the right.
blink.
on the port bar on the right.
bar on the right.
executed immediately.
UMX4x4-Pro2
User's Manual
Autotake
Autotake
Parameters
