8.4.8. View crosspoint size

Description: Shows the physical crosspoint size.
Command {GETSIZE}
Response (SIZE=<size>)CrLf
Explanation: The router reports that it has a 4x4 crosspoint.
Legend: <size> only can be 4x4 in case of UMX4x4-Pro2 matrices.

8.4.9. View LAN versions

Description: Shows information about the LAN interface.
Command {LAN_VER=?}
Response (MAC_ADDR=<mac>)CrLf
Legend:
Explanation: MAC address, web content and web server versions are shown.

8.4.10. View router's health

Description: Queries health status. Response varies depending on the frame type.
Command {ST}
Response (ST●<DESC>)CrLf
Legend:
Explanation: Internal voltages and temperature are shown.
Section 8. Programmers reference
Format
Format
(WEB_VER=<ver1>)CrLf
(SERVER_VER=<ver2>)CrLf
<mac>
MAC (Media Access Control) address of the device.
<ver1>
Version of built-in website user interface (web content).
<ver2>
Version of LAN controller firmware (web server).
Format
<DESC>
INNER VOLTAGE 1 (nominal: 3.3V)
INNER VOLTAGE 2 (nominal 5V)
INNER TEMPERATURE
Example
→ {getsize}
← (SIZE=4x4)CrLf
Example
→ {lan_ver=?}
(MAC_ADDR=00-80-A3-A3-34-20)CrLf
(WEB_VER=1.4.3)CrLf
(SERVER_VER=2.0.5)CrLf
Example
→ {st}
← (ST 3.30V 4.95V 59.2C)CrLf
UMX4x4-Pro2
User's Manual
Page 85 / 136
