8.8.6. Mute specified output

Description: This command mutes an output on a single or multiple layers.
Command {#<out>●<A/V/AV>}
Response (1MT<out²>●<A/V/AV>)CrLf
Legend:
Explanation: The example shows how to mute audio output no. 2.

8.8.7. Unmute specified output

Description: This command unmutes an output on a single or multiple layers.
Command {+<out>●<A/V/AV>}
Response (0MT<out²>●<A/V/AV>)CrLf
Legend:
Explanation: The example shows how to unmute audio output no. 2. Now output 2 is

8.8.8. Lock specified output

Description: This command locks an output on a single or multiple layers.
Command {#><out>●<A/V/AV>}
Response (1LO<out²>●<A/V/AV>)CrLf
Legend:
Explanation: The example shows how to lock audio & video on output no. 4.

8.8.9. Unlock specified output

Description: This command unlocks an output on a single or multiple layers.
Command {+<<out>●<A/V/AV>}
Response (0LO<out²>●<A/V/AV>)CrLf
Legend:
Explanation: The example shows how to unlock audio & video on output no. 4.

8.8.10. Save preset to memory location

Description: Save current crosspoint configuration on one or more layers.
Command {$<id>●<A/V/AV>}
Response (SPR<id²>●<A/V/AV>)CrLf
Legend:
Explanation: Current audio crosspoint state is saved to preset 4, including the mute state
Info: Lock states are not saved. Lock state is assigned to the physical output of the router.
Presets don't affect output locks.
Info: The maximum preset number is limited to 32 for all routers.
Section 8. Programmers reference
Format
Please read section 8.8.1.
Format
Please read section 8.8.1.
switched to the input it was connected to prior to the mute command.
Format
Please read section 8.8.1.
Format
Please read section 8.8.1.
Format
Please read section 8.8.1.
of the outputs. It is possible to save only one layer, in that case the other
layer in the preset will be not affected.
→ {#2 a}
← (1MT02 A)CrLf
(Switch one input to one
→ {+2 a}
← (0MT02 A)CrLf
(Switch one input to one
→ {#>4 av}
← (1LO04 AV)CrLf
(Switch one input to one
→ {+<4 av}
← (0LO04 AV)CrLf
(Switch one input to one
→ {$4 a}
← (SPR04 A)CrLf
(Switch one input to one
UMX4x4-Pro2
User's Manual
Example
output)
Example
output)
Example
output)
Example
output)
Example
output)
