HDCP keycounter
This menu allows to test source devices how many HDCP keys they can accept. Select
the input port with the up ▲ and down ▼ buttons, to which
the tested device is connected to, and then press the
ENTER button to execute keycounter test. Confirmation
message appears: 'Start test? It takes about 1-2 minutes.' The
string to be shown is longer than LCD display line. Wait a
second and the string will be shifted to left character by
character.
Press the ENTER button to start the operation.
A message appears showing the test progress. It can take
several minutes to complete. Interrupt is not allowed during
the HDCP keycount test. Wait with other operations until the
test is finished.
After the test is finished, the result is shown. Press ENTER
to acknowledge the result and return to previous menu.
5.4.5. EDID mode
To enter or to exit from this mode press and release the EDID button. EDID mode is
active when the EDID button is illuminated on the front panel. All EDIDs are referred with
their memory location e.g. F49 or D03, see section
page 34.
Select menu items with the left ◄ and right ► buttons and then press ENTER to step
in submenus.
Info:
You can cancel any not yet executed operation by exiting the EDID menu with pressing
the EDID button.
Info:
Source and destination buttons are disabled while EDID mode is active.
View EDID
If the EDID button is pressed the View EDID submenu opens
automatically. All the stored EDIDs can be checked through
this menu.
The most important information about each EDID is shown in the submenu. The string to
be shown is longer than LCD display line. Wait a second and the string will be shifted to
left character by character.
Use the up ▲ and down ▼ buttons to select the desired EDID. The monitor name and
the preferred resolution can be checked.
Save EDID menu
The EDID from any connected monitor can be learned to user
memory slots.
Select 'Save EDID..' menu items with the left ◄ and right ►
buttons and then press ENTER to step in the submenu.
Select the dynamic EDID of the output port with the up ▲ and
down ▼ buttons. Then press left ◄ or right ► buttons and
select the user EDID slot where the monitor's EDID has to be
stored.
After the desired dynamic EDID and user memory is selected press the ENTER button
to store the EDID.
The 'Operation is progress' message appears on the LCD. If switching the EDID succeed
then the 'Operation done!' message is shown for 2 seconds.
Page 44 / 136
HDCP keycounter
Input #
Start test?
It takes about 1
Trying ## keys..
65%
Finished
Result: # key
5.3
about EDID memory structure on
EDID VIEW F17
LWR 1920x1080@60
Save EDID..
EDID SAV D01>U11
_
Section 5. Operation
