RICOD master:
The video source selection of the remote device
"Video" parameter gives the remote device which video input
port will be selected if it is available:
Info: The LCD menu shows always 8 input ports to control regardless of the remote controlled
device.
Info: All the four cases will take effect only if the remote controlled device is able to perform the
switching command. (e.g. If the remote controlled device is not able to mute its output
port the mute command will be ignored.)
The audio source selection of the remote device
"Audio" parameter gives the remote device which audio input
port should be selected if it is available:
Page 42 / 136
a. 'Disabled': The RICOD function is disabled on
the local device's selected input port. It means the
local device cannot send out RICOD commands
to the controlled device over its input port. (Master
mode is disabled on the selected input.)
b. 'Enabled': The RICOD function is enabled on the
local device's selected input port and the remote
controlled device is unlocked. It means the local
device can send out RICOD commands to the
controlled device over its input port. (Master mode is enabled on the selected
input and the connected slave device is unlocked.)
c. 'Enabled & slave lock': The RICOD function is
enabled on the local device's selected input port
and the remote controlled device is locked. It
means the local device can send out RICOD
commands to the controlled device over its input port. (Master mode is
enabled on the selected input and the slave device is locked.)
a. From the 1st input to the 8th: If the given input
port is available on the remote controlled device it
will be selected.
b. 'Automatic': If Autoselect mode is available on
the remote controlled device it will be selected.
c. 'Muted': If output port muting is available it will be
executed on the video layer.
d. 'Not controlled': If audio switching or locking
command is executed, the selected video input
port won't be changed on the remote controlled
device.
a. From the 1st input to the 8th input: If the given
input port is available on the remote controlled
device it will be selected.
b. 'Automatic': If Autoselect mode is available on
the remote controlled device it will be selected.
c. 'Muted': If output port muting is available it will be
executed on the audio layer.
d. 'Not controlled': If video switching or locking
command is executed, the selected audio input
port won't be changed on the remote controlled
device.
Input 1
RICOD master:Dis
Input 1
RICOD master:Ena
Input 1
RICOD master:Ena
Input 1
Video source:1.
Input 1
Video source:Aut
Input 1
Video source:Mut
Input 1
Video source:Not
Input 1
Audio source:1.
Input 1
Audio source:Aut
Input 1
Audio source:Mut
Input 1
Audiosource:Not
