8.8.3. Switch diagonal
Description: This command switches all video and / or audio outputs to the same
numbered inputs. Output 1 will be switched to the Input 1, Output 2 to Input 2, etc.
Command {<in>@D●<A/V/AV>}
Response (ALLV●<out²>●<out²>●<out²>●<out²>)CrLf
Legend:
Explanation: The example shows how to connect audio and video outputs to the same
8.8.4. View connection on output
Description: This command shows the video connection status of an output.
Command {?<out>}
Response (O<out²>●I<in²>)CrLf
Explanation: The example shows that video output 2 is connected to input 3
Info:
This command is kept for legacy purposes; to get information about all layers, please use
the multilayer command: 8.8.5.
Info:
The response shows connections only for the video layer.
8.8.5. View connection on all outputs
Description: This command displays all connections on a single or multiple layers.
Command {VC●<A/V/AV>}
Response (ALLV●<in²>●<in²>●<in²>●<in²>)CrLf
Legend:
Explanation: The response contains all the connections, if both channels are selected
Info:
If the command is used without the <A/V/AV> parameter, the response prefix is only ALL
(instead of ALLV) but shows only the video layer connections.
Page 96 / 136
Format
(ALLA●<out²>●<out²>●<out²>●<out²>)CrLf
Please read section 8.8.1.
numbered inputs. The response contains all the connections, if both layers
are selected the response is two messages.
Format
(View connection on all
Format
(ALLA●<in²>●<in²>●<in²>●<in²>)CrLf
Please read section 8.8.1.
<in²>
Contains mute & lock state of the output:
M = muted
L = locked
U = muted & locked.
and contains the number of the selected input
(02 = connected to input no. 2)
(M02 = muted output, selected input: no. 2)
(L02 = locked to input: no. 2)
(U02 = muted & locked output, selected input: no. 2)
the response is two messages.
The example shows that output 1,2,3 Audio & Video are connected to input
2 A&V; output 4 video is connected to input 3 and output 4 audio is
connected to input 4.
(ALLV M02 U02 L02 03) response means video output 1 is muted, video
output 2 is muted & locked and video output 3 is locked to input 2.
→ {1@d av}
←
←
(Switch one input to one
→ {?2}
← (O02 I03)CrLf
outputs)
→ {vc av}
← (ALLV 02 02 02 03)CrLf
(ALLA 02 02 02 04)CrLf
(Switch one input to one
Section 8. Programmers reference
Example
(ALLV 01 02 03 04)CrLf
(ALLA 01 02 03 04)CrLf
output)
Example
Example
output)
