Lightware UMX4x4-Pro2 User Manual page 41

Info: If the second item of the priority list was selected (e.g. Analog) and the first item (e.g.
HDMI embedded) appears on the input UMX4x4-Pro2 selects the first one (HDMI
embedded) immediately.
3) The HDCP capability on the input port can be enabled or
4) Navigate to the 'Analog video....' submenu then press the
The 'Analog video' submenu available only if there is a valid analog audio signal on the
Info:
current input port.
Info: UMX4x4-Pro2 examines the analog video signal on the input port and adjusts the analog
video settings automatically. The user can modify these values.
5) Navigate to the 'Analog audio....' submenu then press the
6) Use the left ◄ and right ► buttons to select the 'Remote
Changes take effect immediately, don't need to press the ENTER
Info:
Section 5. Operation
will be placed to the outputs. If there isn't the matrix checks the second item of the
priority list. And so on.
disabled with the HDCP enabled setting. It can be set to
Yes or No. This can prevent unnecessary HDCP
encryption with certain source devices. Note that only
unprotected contents can be played on the source if this setting is No. Use the up ▲
and down ▼ buttons to change the value. For more information about HDCP
handling see section 4.3
ENTER  button to change the analog video settings on
the selected input port. Use the left ◄ and right ►
buttons to select the parameter to be changed. Use the
up ▲ and down ▼ buttons to change the value.
a. Phase
b. H.Pos
c. V.Pos
d. H.Size
e. V.Size
f. Clock
g. Return
Navigate to the 'Return' item then press the ENTER 
button to step back to the 'Analog video' menu.
ENTER  button to change the analog audio settings on
the selected input port. Use the left ◄ and right ►
buttons to select the parameter to be changed. Use the up
▲ and down ▼ buttons to change the value.
Gain
Analog audio gain is the amplify of the built in
preamplifier. It can be set up manually from 0 .. +24 dB.
Navigate to the 'Input 1 Return' item then press the
ENTER  button to step back to the input port settings.
input control...' submenu and press the ENTER  button
to enter into it.
Use the left ◄ and right ► buttons to select the part, and
then use the up ▲ and down ▼ buttons to change the value of that part.
on page 21.
Input #
Phase:0
Input #
H.Pos:455
Input #
V.Pos:41
UMX4x4-Pro2
User's Manual
Input #
HDCP enabled:Yes
Input #
Analog video....
Input #
H.Size:1600
Input #
Clock:2160
Input #
V.Size:1200
Input #
Return
Input #
Analog Audio....
Input #
Gain:0 dB
Input #
Return
Input 1
Remote input con

button.
