8.3.

Storage settings

The matrix stores many configuration settings and parameters and uses different
memories. In some cases it is important to know which setting or parameter will or will not
change after a firmware upgrade.
8.4.

Status and identification commands

8.4.1. View product type

Description: Identification of the device. Type 'i' or 'I' then the router responds its name.
Command {I}
Response (<PRODUCT_TYPE>)CrLf
Legend:
Explanation: The connected device is a UMX4x4-Pro2.

8.4.2. View serial number

Description: The router responds its 8-digit serial number.
Command {S}
Response (<SERIAL_NUMBER>)CrLf
Legend:
Explanation: The connected device's serial number is 59058505.

8.4.3. View Firmware version of the CPU

Description: View the CPU firmware revision.
Command {F}
Response (<FW_VERSION>)CrLf
Legend: <FW_VERSION> is the firmware version. It is followed by <s> string which may
indicate special versions. <s>=r indicates standard version.
Explanation: The connected device's firmware version is 2.0.3r.
Section 8. Programmers reference
Setting or parameter
Matrix router serial number
HDCP options
I/O port and preset names
EDID lists (F, U, D)
EDID emulation table (E)
Input port settings
Output port settings
Crosspoint settings
Crosspoint presets
Serial port settings
IP settings
Analog video timings
Protocol modes
Remote alert send levels
Basic error list
Format
<PRODUCT_TYPE >
Format
< SERIAL_NUMBER > shows the serial number of the router.
Format
After firmware upgrade
remain unchanged
remain unchanged
remain unchanged
remain unchanged
remain unchanged
remain unchanged
remain unchanged
remain unchanged
remain unchanged
remain unchanged
remain unchanged
remain unchanged
remain unchanged
remain unchanged
cleared on reboot
→ {i}
← (I:UMX4x4-Pro2)CrLf
shows the router model.
→ {s}
← (SN:59058505)CrLf
→ {f}
← (FW:2.0.3r)CrLf
UMX4x4-Pro2
User's Manual
Example
Example
Example
