8.12.2. Query RICOD MASTER status on inputs

Description: Checks the status of the previously set RICOD command for the selected
input port.
Command {:RICOD#<in>@<S/A>I=?}
Response (RICOD#<in>@<S>I=<A1><A2>;<B>;
Legend:
Explanation: RICOD control is enabled on the first input port, which unlocks the remote

8.12.3. Set RICOD SLAVE status on output

Description: Enable or disable the reception of RICOD commands over the selected
output port of the local device.
Command {:RICOD_SLEN#<out>@<S/A>O=
Response (RICOD_SLEN#<out>@<S>O=
Legend:
Explanation: RICOD SLAVE functionality is enabled on the first output port on the local

8.12.4. Query RICOD slave status on output

Description: Checks the previously set RICOD status for the selected output port of the
local device.
Command {:RICOD_SLEN#<out>@<S/A>O=?} → {:ricod_slen#1@so=?}
Response (RICOD_SLEN#<out>@<S>O=
Legend:
Explanation: RICOD functionality is enabled on the first output port on the local device.
Page 114 / 136
Format
<C>;)CrLf
Please read section 8.12.1 (Set RICOD MASTER status on
113.
device and selects the second video input and the first audio input port on it.
Format
<num>}
<num>)CrLf
<out> Output port number:
Output number in 1 or 2 digit ASCII format (01,3,04 etc.)
<S/A>: Affected ports:
S = single selected output
A = all outputs
<num> RICOD enable parameter on output:
1: The RICOD SLAVE functionality is enabled on the given
output port. If a RICOD command is detected it will be
executed. (If it is possible.)
0: The RICOD SLAVE functionality is disabled on the given
output port.
Any incoming RICOD command will be rejected.
device.
Format
<num>)CrLf
Please read section 8.12.3 (Set RICOD SLAVE status on
114.
Example
→ {:ricod#1@si=?}
← (RICOD#1@SI=10;2;1;)CrLf
Example
→ {:ricod_slen#1@so=1}
← (RICOD_SLEN#1@SO=1)CrLf
Example
← (RICOD_SLEN#1@SO=1)CrLf
output) on page
Section 8. Programmers reference
input) on page
