Info: This log can contain NOTICEs and WARNINGs under normal operation. These entries do
not mean that there is any problem with the matrix!
Factory reset
This menu contains submenus which can reload factory
defaults for certain group of settings separately. Press the
ENTER  button to enter to the submenus. After selecting an
option (submenu) with the left ◄ and right ► buttons, press
ENTER 
confirmed with ENTER . 'Operation is progress!' message
appears during the executing, and 'Operation done!' message
and a beep sound indicate the successful execute. The 'IO card reset' operation needs to
reboot the matrix.
Select the 'Return' to step back to the main menu.
IP reset submenu
This operation reloads the factory default IP settings.
Parameter
IP address (fix)
port number
Subnet mask
Gateway
Press the ENTER  button to execute IP reset. Confirmation message will be appeared.
String to be shown is longer than LCD display line. Wait a second and the string will be
shifted to left character by character.
Press the ENTER  button again to confirm the operation or press the up ▲ or down ▼
buttons to cancel the operation.
IO card reset submenu
This operation reloads the factory default settings for all input
and output ports. The matrix will reboot after execution.
Press the ENTER  button to execute IP reset. A
confirmation message will be appeared. The string to be
shown is longer than LCD display line. Wait a second and the
string will be shifted to left character by character.
Press the ENTER  button again to confirm the operation or press the up ▲ or down ▼
buttons to cancel the operation.
EDID reset submenu
This operation emulates the factory default F49 EDID
(Universal HDMI) to all input ports.
Press the ENTER  button to execute IP reset. Confirmation
message will be appeared. The string to be shown is longer
than LCD display line. Wait a second and the string will be
shifted to left character by character.
Section 5. Operation
Level
Notice Not an error. Initialization information.
Warning Possible problem without influencing normal operation.
Matter Problem that may lead to further errors.
Error Serious error. Must report to support.
Fatal Fatal error. Normal operation is not possible.
to execute it. Any reset operation has to be
Default value
192.168.254.254
10001
255.255.0.0
0.0.0.0
Description
Factory reset...
Return
IP reset
IP reset?
Press ENTER to p
IO card reset
IO card reset?
Press ENTER to p
EDID reset
EDID reset?
Press ENTER to p
