Temperature (Predictive)
Range:
Display Resolution:
Accuracy:
Datascope SpO
2
Range:
Display Resolution:
Display Update:
Calibration:
Accuracy - Datascope:
Pulse Rate Range
Pulse Rate Accuracy
®
Nellcor SpO
2
Range:
Display Resolution:
Display Update:
Calibration:
®
Accuracy - Nellcor :
Pulse Rate Range
Pulse Rate Accuracy
Neonatal accuracy specifications are based upon testing the N-3000 and N-25 neonatal
sensors on healthy adult volunteers in induced hypoxia studies, in the range of 70-100%
SpO . The specified accuracy also takes into account published literature which predicts
2
that there may be a small difference in % SpO
ments from adult and fetal blood with 100% fetal hemoglobin are compared. Fetal
hemoglobin is present in concentrations varying from 10% to 90% in neonatal blood,
and this percentage declines over time. As the percentage of fetal hemoglobin in neonatal
blood declines, the theoretical effect on accuracy due to this source is reduced".
Accutorr Plus Service Manual
Chapter 3 - Specifications
90-110° F, 32-43° C
0.1° F, 0.1° C
Meets ASTM E1112-86 for accuracy.
40-100% SpO
2
1% SpO
2
Less than 4 seconds
Factory Calibrated to Functional Saturation
± 2% from 70 - 100% SpO
± 4% from 60 - 69% SpO
2
unspecified from 40-59% SpO
30 to 250 BPM
"3 BPM or 3% of the reading, whichever is greater.
40-100% SpO2
1% SpO
2
Less than 4 seconds
Automatic
± 2 digits from 70 - 100% SpO
± 3 digits from 70 - 100% SpO
unspecified from 40-69% SpO
21 to 249 BPM
"3 BPM.
reported by the oximeter when measure-
2
2
2
- Adult
2
- Neonates
2
2
Revised 02/15/00
