Alarm Violations - Datascope Accutorr Plus Service Manual

Alarm Limit Table
PARAMETER
Systolic High
Adult
Pediatric
Neonate
Systolic Low
Adult
Pediatric
Neonate
Diastolic High
Adult
Pediatric
Neonate
Diastolic Low
Adult
Pediatric
Neonate
MAP High
Adult
Pediatric
Neonate
MAP Low
Adult
Pediatric
Neonate
Pulse Rate High
Adult
Pediatric
Neonate
Pulse Rate Low
Adult
Pediatric
Neonate
SpO2 High
Adult
Pediatric
Neonate
SpO2 Low
Adult
Pediatric
Neonate

1.3.5.2 Alarm Violations

An alarm condition exists if the parameter is equal to or is outside the high/low limit
range that has been set. When an alarm limit is violated, the following actions occur:
·
The LEDs for the parameter in an alarm condition flashes.
·
The parameter in an alarm condition is in reverse video on the LCD (Accutorr Plus models
with Trend Screen).
·
The alarm tone is sounded (unless muted with the MUTE key (30)).
·
The parameter(s) that was in an alarm condition will be in brackets [ ] when printed on
the recorder.
1-26
RANGE UNITS
Off, 60-260
Off, 60-160 mmHg
Off, 50-125
Off, 55-150
Off, 55-130 mmHg
Off, 45-115
Off, 40-200
Off, 40-150 mmHg
Off, 35-100
Off, 30-120
Off, 30-50 mmHg
Off, 25-50
Off, 90-200
Off, 90-150 mmHg
Off, 60-110
Off, 40-100
Off, 40-70 mmHg
Off, 30-70
Off, 100-245
Off, 100-245 bpm
Off, 100-245
Off, 35-120
Off, 35-150 bpm
Off, 75-200
Off, 61-99
Off, 61-99 %SpO2
Off,61-99
60-95
60-95 %SpO2
60-95
FACTORY UNITS OF
DEFAULT INCREMENT
Off 5
Off 5
Off 5
Off 5
Off 5
Off 5
Off 5
Off 5
Off 1
86 1
