Datascope Accutorr Plus Service Manual page 196

CPU/LED Board
Item Part Number
No.
88 0326-01-7680
89 0326-01-8063
90 0326-01-9533
91 0388-00-0650
92 0432-00-0005
93 0136-10-0023
95 0155-90-0413
96 0155-90-0412
97 0136-10-0015
98 0012-00-1236
99 0326-01-2212
6-34
Revised 12/20/00
Description
RESISTOR SMD THICK FILM
1/10W 1%, 768
Resistor SMD Thick Film 1/10W
1%, 806K
Resistor SMD Thick Film 1/10W
1%, 953K
PCB, CPU MODULE
MOUNTING, 0.28" LED
MOUNTING, 0.8" LED
IC, Programmed, Accutorr
IC, Programmed, Accutorr
MOUNTING, 0.56" LED
Cable Assembly, Module, 20 pin
IDC PC mount to 20 pin card edge
receptacle
Resistor SMD Thick Film 1%, 22.1K R91
0670-00-0650-03/04
Reference
R51
R41
R76
XDS13, XDS14, XDS15
2 per for DS2&DS4, DS3&DS5 and DS1&DS4
U3
U27
for DS7- DS12
J4
