1.3.8 SETTING THE LCD CONTRAST (View Angle Adjustment)

The LCD on the Accutorr Plus models with Trend Screen can be adjusted for optimum
viewing. The MENU key (8) and the LCD Up and Down Arrow keys (9 & 10) are used
to adjust the contrast.
1. Press and hold the MENU key (8) (2 beep tones, approx. 3 seconds). A beep tone is
generated when the key is first pressed and the display changes to the menu. When a
second beep tone is generated, release the key.
2. To quickly adjust the contrast, press and hold either the LCD Up or Down Arrow
key (9 or 10). For fine adjustment, momentarily press either the LCD Up or Down
Arrow key.
3. The LCD contrast adjustment is saved by either pressing the MENU key (8) again or
not pressing either the LCD UP or Down Arrow keys (9 & 10) for 15 seconds.
NOTE: The contrast setting will be the same each time the unit is turned on, unless
readjusted by the user.
