Datascope Accutorr Plus Service Manual page 100

Masimo
Range:
Display Resolution:
Display Update:
Calibration:
SpO
2
Saturation during
No Motion Conditions
Adults:
Neonates:
SpO
2
Saturation during
Motion Conditions:
Adults:
Neonates:
Pulse Rate Range:
Pulse Rate Accuracy:
1
The Masimo MS-3 pulse oximeter with
no motion accuracy in human blood studies on healthy adult volunteers in induced
hypoxia studies in the range of 70% to 100% SpO
and ECG monitor. This variation equals plus or minus one standard deviation.
Plus or minus one standard deviation encompasses 68% of the population.
2
The Masimo MS-3 pulse oximeter with LNOP
for motion accuracy in human blood studies on healthy adult volunteers in
induced hypoxia studies while performing rubbing and tapping motions at 2 to 4
Hz. At an amplitude of 1 to 2 cm and non-repetitive motion between 1 to 5 Hz.
At an amplitude of 2 to 3 cm in induced hypoxia studies in the range of 70% to
100% SpO
equals plus or minus one standard deviation. Plus or minus one standard
deviation encompasses 68% of the population.
3-4
Revised 06/19/01
®
SpO
2
Accuracy
1
:
Accuracy
2
against a laboratory co-oximeter and ECG monitor. This variation
2
40-100% SpO
2
1% SpO
2
Less than 4 seconds
Automatic
70% to 100% ± 2 digits
70% to 100% ± 3 digits
40 to 69% SpO unspecified.
2
70% to 100% ± 3 digits
70% to 100% ± 4 digits
26 to 239 BPM
"3 BPM
LNOP Adt sensors have been validated for
against a laboratory co-oximeter
2
Adt sensors has been validated
Accutorr Plus Service Manual
Chapter 3 - Specifications
