11. Select Key (Accutorr Plus models with Trend Screen)
When the menu screen is displayed in the LCD, this key is used to select the menu
items. When the back light in the LCD is off, pressing this key turns it on.
12. Print Key
Press this key to print all stored information for the selected patient. Press to stop a
printing that is in process. Press and hold this key (2 single beep tones, approx. 3
seconds) to change the print mode between Continuous and Request. When in the
Continuous mode, the PRINT Indicator LED is illuminated. When loading in a new
roll of recorder paper, press this key to feed the paper through the printer.
13. Print Indicator
This indicator is illuminated when continuous printing of measurements is selected.
14. Defaults Key
Press and hold this key (2 single beep tones, approx. 3 seconds) to reset all parameters
back to the hospital default settings. This includes alarms, inflation pressure, interval,
etc... When in the process of making a change to a setting, you can return to the
original setting by momentarily pressing this key. To enter the User Configuration,
press and hold this key (1 beep tone), while turning the unit on. See section 1.3.15
for details on default settings and User Configuration.
15. SpO Connector (Accutorr Plus model with Datascope, Nellcor
2
This connector is used to attach Datascope, Nellcor
16. AC Power Indicator
This green illuminates whenever
LED
17. Battery Indicator
This green illuminates whenever the unit is operating on battery power. The
LED
LED will flash when the battery requires charging. When the LED begins flashing,
approximately 30 minutes of battery time remain on the Accutorr Plus NIBP (20
minutes on the Accutorr Plus NIBP with Trend Screen and 10 minutes on the
Accutorr Plus NIBP with Trend Screen and SpO
18. NIBP Connector
This connector is used to attach specified NIBP hoses.
19. On/Standby Key
This key is used to activate the unit, enabling it to begin taking measurements. The
unit does not have to be "ON" for the internal battery to charge. However, the unit
does need to be plugged into an AC receptacle for the battery to be charging.
20. Memory Full Indicator
This LED indicator flashes when 80 - 99 of the 100 available entries of trend are
used. This LED is on continuously when 100 are used. Delete measurements
manually using the DELETE INFO. key or the unit will automatically delete the
oldest measurement for the current patient. NOTE: The unit will also automatically
delete data that is 24 hours old.
Accutorr Plus Service Manual
Chapter 1, Operation
or Masimo SpO
®
power is applied to the unit.
AC
2).
or Masimo SpO )
®
2
sensors.
2
Revised 02/15/00
1-9
