6.8.2 Recorder Module Isometric Parts List
Figure
No.
Description
1
Chart Paper Door
2
Chart Cutter
3
Recorder Main Housing
4
Printer Assembly w/printhead
5
Circuit Board, Includes Printer
6
Plastic Shield, Anti Static
N/S*
Label, Serial Number
N/S*
Label, Recorder Paper Replacement
N/S*
Captive Screw for Mounting
N/S*
Captive Washer for Above
*N/S are items not shown on drawing.
Accutorr Plus Service Manual
Chapter 6 - Parts
Datascope
Part Number
0380-00-0274
0380-00-0275
0380-00-0273-01
0161-00-0015
0670-00-0583-01
0349-00-0251
0334-00-1304
0334-00-1435
0217-02-0003
0221-00-0121
Revised 12/20/00
6-13
