Datascope Accutorr Plus Service Manual page 191

SpO Board Assembly
2
Item Part Number
No.
46 0287-00-1103
47 0287-01-1104
48 0289-01-2106
49 0289-01-2226
50 0307-11-0472
51 0320-00-1004
52 0320-00-2913
53 0320-00-5302
54 0324-01-10R0
55 0324-01-22R1
56 0324-01-27R4
57 0326-00-0106
58 0326-01-1001
59 0326-01-1002
60 0326-01-1003
61 0326-01-1004
62 0326-01-1243
63 0326-01-1333
64 0326-01-1472
65 0326-01-1502
66 0326-01-1503
67 0326-01-1621
68 0326-01-1652
69 0326-01-2003
70 0326-01-2320
71 0326-01-3013
72 0326-01-3241
73 0326-01-3742
74 0326-01-3922
75 0326-01-3923
76 0326-01-4750
77 0326-01-4751
78 0326-01-4752
79 0326-01-4753
80 0326-01-5111
81 0326-01-6653
82 0326-02-1002
83 0388-00-0593
84 0212-12-0403
85 0406-00-0693
86 0349-00-0276
87 0153-00-0197
88 0361-09-0402
89 0136-57-0085
90 0136-22-0040-01 Test Point
Accouter Plus Service Manual
Chapter 6 - Parts
Description
CAP .01 UF 50V 10% CER
CAP .1UF 25V 10% CER
CAP 10 UF 35V 20% ALUM
CAP 22 UF 35V 20% ALUM
Resistor Network (x4), 4.7K,
0.063W
RES 1 M .1% .1W
RES 291K .1% .1W
RES 53.OK .1% .1W
RES 10 ohm 1% 1/4W
RES 22.1 ohm 1% 1/4W
RES 27.4 ohm 1% 1/4W
RES 10M 5% .1W
RES 1K 1% .1W
RES 10K 1% .1W
RES 100K 1% .1W
RES 1M 1% .1W
RES 124K 1% .1W
RES 133K 1% .1W
RES 14.7K 1% .1W
RES 15K 1% .1W
RES 150K 1% .1W
RES 1.62K 1% .1W
RES 16.5K 1% .1W
RES 200K 1% .1W
RES 232 ohm 1% .1W
RES 301K 1% .1W
RES 3.24K 1% .1W
RES 37.4K 1% .1W
RES 39.2K 1% .1W
RES 392K 1% .1W
RES 475 1% .1W
RES 4.75K 1% .1W
RES 47.5K 1% .1W
RES 475K 1% .1W
RES 5.11K 1% .1W
RES 665K 1% .1W
RES 10K .1% .1W
PCB, SpO2
Screw, Pan Head
Bracket
Insulator, SpO
2
Diode Suppressor
PEM SS Standoff (KFSE-440-4)
PLCC Socket
0670-00-0593-03
Reference
C28,C50
C25-27,C52
C64,C67,C69,C70,C71,C72
C45,C47,C73,C74,C75
RN1,RN2,RN3,RN4
R22
R21
R94
R3,R10,R30,R46
R2
R1
R34
R7,R11,R12,R15,R28,R33,R44,R55,R62,R67,R69,R
72,R77,R90, R104
R6,R17,R23,R24,R38,R40,R61,R70,R71,R75,R82,R
102,R111,R112
R9,R14,R16,R27,R36,R51,R74
R45,R49,R85,R91
R42,R59,R65,R87
R4
R47
R43
R39,R41,R52,R58,R60,R66,R73,R83,R84
R68,R92
R37
R8
R76,R89
R80
R25
R88
R29,R57
R18,R31
R108
R13
R53,R63
R26
R32,R48
R5
R19,R20,R35,R50,R54
Not used in -03 boards
Not used in -03 boards
D6,7,8,9
XU34
TP6,TP7
Revised 12/18/00
6-29
