1.2.3 Predictive Thermometer Module (PTM)
Figure 1-6 Predictive Thermometer Module
49. Probe Cover Holder
Used to store a box of probe covers.
50. Probe Chamber
Used to store the temperature probe when not in use.
51. Probe Connector
Used to connect the thermometer probe to the PTM module.
1-14
49
50
51
