Datascope Accutorr Plus Service Manual page 203

Power Sup ply, Lith ium Ion
Item Part Num ber De scrip tion
No.
91 Res SMT 1.50K Ohm 1% 0805
92 Res SMT 16.50K Ohm 1% 0805
93 Res SMT 17.80K Ohm 1% 0805
94 Res SMT 221.00 Ohm 1% 0805
95 Res SMT 2.21K Ohm 1% 0805
96 Res SMT 22.10K Ohm 1% 0805
97 Res SMT 3.32M Ohm 1% 0805
98 Res SMT 33.20 Ohm 1% 0805
99 Res SMT 475.00 Ohm 1% 0805
100 Res SMT 4.75K Ohm 1% 0805
101 Res SMT 47.50K Ohm 1% 0805
102 Res SMT 47.50 Ohm 1% 0805
103 Res SMT 54.90K Ohm 1% 0805
104 Res SMT 6.19K Ohm 1% 0805
105 Res SMT 150.00KOhm 0.1% 1206
106 Wire Jumper
107 Wire Jumper
108 Sleeving Heatshrink BLK 3/4"
109 Conn Hdr .1 Ctr Locking 14 Pos
110 Conn Hdr Amp 640445-3
111 HEADER-3 POS,.312 CEN TERS
112 NUT,ASSEM LK WASH.,6-32,SM PAT
113 Screw PnHd 4-40 X .312 Phil
114 Washer Flt Stl Nar row 0.25 OD
115 WASHER,SPLIT LOCK, #4
116 Screw UC FLT HD 4-40 .312
117 In su la tor,Nomex,MSP1510
118 Clamp TO-220 Ny lon
119 In su la tor Silpad 0.6" X 0.87"
120 Screw FH 100 Deg 6-32 X 0.500"
121 Screw FH 100 Deg 6-32 X 0.625"
122 Clamp Bar GPFC110
123 SPRINGCLIP,MOUNTING,TO-220
124 STAND OFF,SWAGE,4-40 x .250
125 In su la tor Silpad 0.6" X 0.87"
126 Fuse Mi cro Time-Lag 4.00A 250V
127 Tubing Tef lon Clear 20GA
128 LA BEL-BARCODE,MSP1698
129 CAP AL LO-Z 105C 25V 560MF
Accutorr Plus Service Manual
Chapter 6 - Parts
Ins 22GA 0.300"
Ins 18GA 0.750"
0014-00-0225
Ref er ence
R42,96
R37
R72,86
R12,20,92
R26,29
R15,41
R56
R89
R6,33,35,61,77
R11,55,66,94
R24,38,81,91
R3,60,80
R27
R8,51
R49
W1
FOR: F3
For: M1
J3
J4
J2
FN11
FN3
FN4
FN2
FN12
FN8
FN5
FN6
FN7
FN10
FN9
FN3
FN4
FN2
F1,2
FOR R59
FN13
C60,C14,C17
