Datascope Accutorr Plus Service Manual page 168

Fig ure
No.
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
37a
37b
38
38a
39
40
40a
40b
40c
40d
41
41a
42
43
43a
44
45
46
47
48
48a
6-6
De scrip tion
Washer, shoul der, cam latch
Spring, tor sion, cam latch
Cam latch with rub ber fric tion tape
Fric tion strip, ad he sive
Re lease han dle
Rear hous ing com plete with # 21-26
In ter face ca ble, NIBP to power sup ply
In ter face ca ble, NIBP to CPU
NIBP cir cuit mod ule
In ter face ca ble, NIBP to Fil ter PCB
In ter face ca ble, NIBP to LCD Power Sup ply
Shield, plas tic for NIBP
Mo tor fil ter cir cuit board
In verter cir cuit for LCD backlite
Bracket, for In verter and Mo tor fil ter
Com pres sor for NIBP, 12 VDC
Ca ble for pump with quick con nect term.
In su la tor, NIBP con nec tor
Plas tic push fas ten ers for SpO
Plas tic fas ten ers for Masimo shield
Bracket for NIBP pump
SpO cir cuit board, Datascope
2
SpO cir cuit board, NELLCOR
2
In ter face board for NELLCOR
SpO2 cir cuit board, Masimo
In ter face board for Masimo
Power sup ply / batt. charger, sealed lead acid
Power sup ply / batt. Charger, Li-Ion
In su la tor tub ing, PVC, .75"
SpO2 board shield, NELLCOR
SpO2 board shield, Masimo
Shield, metal for NIBP mod ule
Com mu ni ca tion cir cuit board
Screw for rear hous ing (4-40 x 1.25")
Screw for rear hous ing (6-32 x .313")
Bat tery door, with plas tic hinge
Bat tery door, re place ment only
shield
2
®
®
SpO
2
®
®
SpO
2
®
®
Accutorr Plus Service Manual
Datascope
Part Num ber
0221-00-0139
0214-00-0229
0380-00-0267
0215-00-0107
0380-00-0268
0380-00-0357-02
0012-00-0943
0012-00-0944
0670-00-0584-02
0012-00-0986
0012-00-0989
0349-00-0265
0670-00-0584-03
0670-00-0649
0406-00-0671
0104-00-0008
0012-00-1015
0349-00-0314
0344-00-0242
0344-00-0249
0343-00-0098
0670-00-0593-03
0671-00-0162
0670-00-0675
0671-00-0055
0670-00-0716
0014-00-0184
0014-00-0225
0008-00-0324
0349-00-0306
0337-00-0134
0337-00-0120
0670-00-0661-01
0212-12-0420
0212-12-0605
0380-00-0358-02
0380-00-0358-01
Chapter 6 - Parts
