LCD Backlite Power Supply Board
Item Part Number Description
No.
1 0014-00-0180 Power Supply, DC to AC inverter
2 0136-91-0003 CONNECTOR PC, Header,right angle
3 0136-91-0004 COINNECTOR PC, Header, right angle
4 0151-00-0195 Transistor, IRLD014 MOS FET
5 0153-00-0001 Diode, IN4003
6 0283-04-0104 CAP, 0.1uF 10%, 100V Ceramic
7 0290-01-1221 CAP, 220uF, 5%, -10%, 25V Alum
8 0315-00-0104 RES., 100K 5%, 1/4W
9 0385-00-0649 PCB, LCD Power
10
6-30
Revised 12/20/00
0670-00-0649
Reference
T1 - ERG - JLA 12-202P
J2
J1
Q1
D1
C1,C3
C2
R1
Accutorr Plus Service Manual
Chapter 6 - Parts
