21. Delete Info. Key
Press the Data Scan key to enable the Delete Info. key (Accutorr Plus without Trend
and SpO
to delete the most recent reading when it is displayed. When displaying any
measurement, press and hold this key (2 beep tones, approx. 6 seconds) to delete all
information for the currently selected patient. Press and hold at power up to delete
all information for all patients.
22. Data Scan Key
Press this key (1 beep tone) to view previous measurements for the selected patient
on the Accutorr Plus NIBP and to enable the Delete Info. key (Accutorr Plus with-
out Trend and SpO
Accutorr Plus NIBP, use the Patient Info. Up & Down Arrow keys (27 & 28) to
scroll through the stored measurements for the selected patient. On all models of the
Accutorr Plus, press and hold this key (2 beep tones, approx. 6 seconds) to scan all of
the rooms and beds for stored measurements. Press the Data Scan key again to stop
on a particular room/bed. Press the Data Scan key again to exit this view mode.
23. Data Scan Indicator
This LED indicator is illuminated when viewing prior data.
24. Room/Bed Number Key
Press this key to change the displayed Room/Bed. After pressing this key use the
Patient Info. Up & Down Arrow keys (27 & 28) to change the Room/Bed. This key
is also used when selecting a User Configuration item.
25. Bed Letter Display
This display is used to show the current patient bed letter. It is also used to display
status codes for NIBP, SpO
items.
26. Room Number Display
This display is used to show the current patient room number. It is also used to
display status codes for NIBP, SpO
being set (Hi or Lo), and displays a User Configuration item.
27. Patient Info. Down Arrow Key
This key is used to decrement the alarm limits when they are shown on the LED
displays and to decrement the hours, minutes, month, day and year in the clock set
mode. This key is also used to change the Room/Bed, to scroll through previous data
and to change initial inflation pressure.
28. Patient Info. Up Arrow Key
This key is used to increment the alarm limits when they are shown on the LED
displays and to increment the hours, minutes, month, day and year in the clock set
mode. This key is also used to change the Room/Bed, to scroll through previous data
and to change initial inflation pressure.
1-10
only). Once enabled, press and hold this key (1 beep tone, approx. 3 seconds)
2
only). The LED indicator next to the key illuminates. On the
2
and Temperature and to display User Configuration
2
2
and Temperature, indicates which alarm is
