1.3.6.2 To View the Stored Measurements on the Accutorr Plus NIBP with Trend
Screen and the Accutorr Plus NIBP with Trend Screen and SpO
The stored measurements on the Accutorr Plus models with Trend Screen are displayed in the
LCD. Up to 5 stored measurements are displayed at one time. Measurements are displayed in
time order, with the newest measurement at the top. A scroll bar with one or both arrows will
display on the side of the LCD when more measurements are available to view. When only
one arrow displays, more measurements are only available in the direction of the arrow.
1. To view more measurements press the LCD Up or Down Arrow key (9 & 10).
Time
Date
20/05 03:00
20/05 02:58
20/05 02:35
20/05
02:33
20/05 02:30
Figure 1-10 - LCD Trend List Display

1.3.6.3 To Delete the Stored Measurements on all Models of the Accutorr Plus

While viewing stored data, you can delete the most recent measurement or all of the
stored measurements for the currently displayed patient.
1. Select a room/bed where stored information can be deleted. (See section 1.3.2.3 for
details on selecting a room/bed.) If it is the currently displayed room/bed, go to step
2. When you are uncertain what rooms/beds have stored data, press and hold the
DATA SCAN key (22) (2 beep tones, more than 3 seconds). The Accutorr Plus will
scan through all of the rooms/beds that have data stored. To stop on a Room/Bed as
the Accutorr Plus is scanning, press the DATA SCAN key (22). NOTE: The Accutorr
Plus will scan through the rooms/bed with stored data only once.
2. On the Accutorr Plus NIBP only, when the desired room/bed is displayed, press the
DATA SCAN key (22) (1 beep tone). The DATA SCAN Indicator (23) illuminates.
3. When the most recent stored data is displayed, press and hold the DELETE INFO.
key (21) (1 beep tone, approx. 3 seconds) to delete this measurement.
4. When viewing any of the stored measurements, press and hold the DELETE INFO.
key (21) (2 beep tones, approx. 6 seconds) to delete all stored measurements for the
current patient. When all data is cleared the patient size will be the default selection.
5. On the Accutorr Plus NIBP only, press the DATA SCAN key (22) (1 beep tone) to
exit the delete data mode.
NOTE: The unit will also automatically delete data that is 24 hours old.
NOTE: To delete all information for all patients, press and hold the DELETE INFO. key
(21) while powering on the unit.
Accutorr Plus Service Manual
Chapter 1, Operation
o F/C
S / D / M
61 98.7
114/64 83
123/61 60
84 98.5
127/62 83 58
97.6
185/105 56
135 ----
98.2
129/62 84 59
Alarm Violated Measurement
2
%SPO2
96
97
Scroll
Bar
96
96
97
1-29
