Datascope Accutorr Plus Service Manual page 7

7.5.13 Verification of Accutorr Plus Pneumatic Performance,
Using the "Cufflink" NIBP Emulator (11d) . . . . . . . . . 7-11
7.5.14 Over Pressure Transducer Verification (12c, 12a, 12b) . 7-12
7.5.15 Main Pressure Transducer Calibration. . . . . . . . . . . . . . 7-12
7.5.16 Over Pressure Transducer Calibration . . . . . . . . . . . . . . 7-13
7.5.17 Battery Selection (13) . . . . . . . . . . . . . . . . . . . . . . . . . . 7-13
7.6 Predictive Thermometer Verification and Calibration. . . . . . . . . . 7-14
7.6.1 Temperature Accuracy Verification with the
Predictive Temperature Simulator . . . . . . . . . . . . . . . . 7-14
7.6.2 Water Bath Method . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-15
7.6.3 System Calibration Procedure . . . . . . . . . . . . . . . . . . . . 7-15
7.6.4 Temperature Verification Test, Infrared
Thermometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-16
7.6.5 Low Battery Sensing . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-17
7.7 Battery Test for Accutorr Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-18
7.7.1 Low Battery Indicator and Low Battery Cut-Off . . . . . . 7-18
7.7.2 Set the Current Time . . . . . . . . . . . . . . . . . . . . . . . . . . 7-19
7.8 NIBP Normal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-20
7.9 Trend Memory Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-21
7.10 SpO Normal Operation (Accutorr Plus with SpO
2
8.0 PREVENTIVE MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . 8-1
8.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
8.2 Limitations of Physiological Simulators . . . . . . . . . . . . . . . . . . . . 8-1
8.3 Preventive Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
8.3.1 Mechanical and Physical Visual Inspection
(One Year Interval) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
8.3.2 Electrical Safety and Performance Checks
(One Year Interval) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Accutorr Plus Service Manual
Introduction
only) . . . . . . . 7-21
2
Revised 09/20/07
vii
