Datascope Accutorr Plus Service Manual page 190

SpO Board Assembly
2
Item Part Number
No.
1 0108-00-0019
2 0108-00-0020
3 0108-00-0058
5 0136-00-0201
6 0136-85-0010
7 0151-00-0182
8 0151-00-0184
9 0153-00-0168
11 0153-00-0175
12 0153-00-0176
13 0155-00-0591-03 IC uPROCESSOR 63X09E
14 0155-00-0629
15 0155-00-0631
16 0155-00-0632
17 0155-00-0633
18 0155-00-0635-01 IC MICRO MONITOR
19 0155-00-0645
20 0155-00-0714
21 0155-00-0716
22 0155-00-0717
23 0155-00-0718
24 0155-00-0719
25 0155-00-0720-01 IC DG201 QUAD SPST ANALOG
26 0155-00-0721-03 IC 32KX8 STATIC RAM
27 0155-00-0753
28 0155-00-0822-01 IC TRI-STATE OCTAL 74HCT534
29 0155-00-0901-03 IC DUART, SCC2692AC1A44
30 0155-90-0235
31 0155-90-0297
32 0155-90-0298
33 0158-07-0012
34 0158-08-0005
35 0283-00-0056
36 0283-04-0474
37 0285-08-8201
38 0285-15-0104
38 0285-15-2104
39 0285-15-0223
39 0285-15-2223
40 0286-00-2101
41 0286-00-2102
42 0286-00-2220
43 0286-00-2221
44 0286-00-2470
45 0286-00-2471
6-28
Revised 06/01/01
Description
Penta-filar wound
Tri-filar wound
Ferrite Bead
Test Point
CONNECTOR PC, Header,
shrouded right angle w/ejector
XSTR 5308 SMD
XSTR 2222A SMD
DIODE, SMD, 5239B
DIODE 914/4148 SMD
DIODE 6263 SMD
IC VOLTAGE REF 1004
IC PRCN OP-AMP OP-27
IC 12 BIT MULTI. DAC AD7541A
IC BI-FET SMP-HLD LF398
IC OPAMP TL032
IC HEX INVERTER 74HCT04
IC TL082CD
IC PRECISION OP-AMP
IC LM 337LM
IC LM317LM
SW
IC COMPARATOR LM 311
IC PROGRAMMED PLD EP910I
IC PROGRAMMED FLASH ROM
(To be socketed.)
IC PROGRAMMED PLD EPM7032
CRYSTAL, CLOCK OSCILLATOR
Xtal, SMD, 3.6864 MHz.
CAP .1UF BYPASS
CAP .47 UF 50V 10% CER
CAP .0082uF POLYPROPYLENE
CAP POLYCARB. .1UF 63V 2.5%
CAP POLYCARB. .1UF 50V 1%
CAP POLYCARB. .022 UF 100V 2.5% C61-63,C66
CAP POLYCARB. .022 UF 75V 1% C61-63,C66 (Alternate)
CAP 100PF 100V 5% CER
CAP 1000PF 50V NPO
CAP 22PF 100V 5% CER
CAP 220PF 100V 5% CER
CAP 47 PF 100V 5% CER
CAP 470PF 100V 5% CER
0670-00-0593-03
Reference
U17
U16
L1,L2,L3,L4
TP1-TP5, TP8-TP11
J1,J3
Q1,Q2, Q3
Q4
CR2
CR1,5,6,9,12,14,15,16,17
CR7
U34
U25
U4,U21
U29
U13
U35
U8,U9,U22
U30
U1,U2,U11
U6,U7
U28
U27
U3,U5,U10,U12
U18
U36
U33,U39,U40
U14
U24 Blank chip is 0155-00-0494-12 (EP910ILC-15)
U26 Blank chip is 0155-00-0634-01
(AM29F010-90JC)
U23 Blank chip is 0155-00-0673-11
(EPM7032LC44-15)
U31
Y1
C6-24,C30-34,C36-38,C41
C1-5
C68
C58-60,C65
C58-60,C65 )Alternate)
C49
C40,C42
C29,C35,C48,C51,C53,C54
C56
C55
C57
Accutorr Plus Service Manual
Chapter 6 - Parts
