Datascope Accutorr Plus Service Manual page 204

Nellcor Interface BD
Item Part Number Description
No
1 0014-00-0047 POWER SUPPLY, ISOLATED DC/DC CONVERTER, 5V
TO 5V
2 0014-00-0200 POWER SUPPLY, DC/DC CONVERTER, 1W, +/- 9V
3
4 0108-00-0095 INDUCTOR, POWER SMD, 22uH
5 0136-00-0201 CONNECTOR, TEST POINT
6 0136-00-0287-07 CONNECTOR, RECEPTACLE, DUAL ROW
7 0136-85-0010 CONNECTOR, HEADER, SHROUDED RIGHT ANGLE
W/EJECTOR
8 0136-91-0003 CONNECTOR, HEADER, RIGHT ANGLE LOCKING
AND POLARIZED
9 0136-91-0004 CONNECTOR, HEADER, RIGHT ANGLE LOCKING
AND POLARIZED
10
11 0153-00-0209 DIODE, MBRS130L, SCHOTTKY POWER RECTIFIER,
30V
12 0155-00-0775 IC, +5V REGULATOR, 78L05A
13 0155-00-0776 IC, -5V REGULATOR, 79L05A
14 0155-00-0791-01 IC, QUAD, 2 INPUT NAND GATE, 74HCT00
15 0155-00-1007-01 IC, HCPL2212, OPTOCOUPLER, LOGIC OUTPUT
16 0155-00-1007-02 IC, HCPL2232, OPTOCOUPLER, LOGIC OUTPUT
17 0155-00-1062-01 IC, MAX710, 3.3/5V STEP-UP/DOWN DC/DC CON-
VERTER
18
19 0287-00-1104 CAPACITOR, SMD 0805, CERAMIC X7R, 10%, 0.1UF
20 0289-00-5475 CAPACITOR, SMD, TANTALUM, 20%, 4.7UF
21 0289-02-3107 CAPACITOR, SMD, TANTALUM SWITCH MODE,
100UF
22 0289-02-5336 CAPACITOR, SMD, TANTALUM SWITCH MODE, 33UF C8,C10
23 0325-01-1001 RESISTOR, THIN FILM, 1/8W, 1%, 1206, 1K
24 0325-01-1002 RESISTOR, THIN FILM, 1/8W, 1%, 1206, 10K
25
26
27 0361-00-0752 Support Post, PCB Lock Mount, Nylon
28 0361-09-0402 Standoff, Broaching type PCB
29 0388-00-0675 PCB, Nellcor Interface Board
30
31 0060-00-0979-01 Module Specification, Nellcor Interface Board
32 0060-00-0979-02 Design Documentation, Nellcor Interface Board
33 0060-00-0979-03 Worst Case Analysis, Nellcor Interface Board
34 0060-00-0979-05 Design Validation, Nellcor Interface Board
35 0060-00-0979-06 Production Test Specification, Nellcor Interface Board
6-42
Revised 12/20/00
P/N 0670-00-0675
Reference
T1
T2
L1
TP1(GND), TP2(+5V), TP3(RX),
TP4(RST*), TP5(TX),
TP6(+5AN), TP8(+5DIG),
TP9(-5AN)
J2
J1
J3
J4
D1-D3
U4
U5
U3
U2
U1
U6
C1-C3,C6,C9,C11
C7
C4,C5,C98,C99
R3-R5, R7
R1,R2, R6
Accutorr Plus Service Manual
Chapter 6 - Parts
