Datascope Accutorr Plus Service Manual page 58

User
Configuration
Number
5c
5d
6a
6b
6c
7
8
9a
9b
9c
10a
10b
11
12
1-50
Revised 02/15/00
Function Description
Time Out, Light Set how long the light will stay
in the LCD when on, when no keys are pressed, in
the unit is powered the LCD. The choices are: 3, 5, 10
from AC mains. or 15 minutes.
Time Out, Light Set how long the light will stay
in the LCD when on, when no keys are pressed, in
the unit is the LCD. The choices are: 3, 5, 10
powered from the or 15 minutes.
internal battery.
Adult Initial Set the initial cuff inflation pressure
Inflation Pressure for an adult size patient. The
choices are: 100 to 260 mmHg at
5 mmHg increments.
Pediatric Initial Set the initial cuff inflation pressure
Inflation Pressure for a pediatric size patient. The
choices are: 60 to 180 mmHg at 5
mmHg increments.
Neonate Initial See the initial cuff inflation
Inflation Pressure pressure for a neonate size patient.
The choices are: 40 to 120 mmHg
at 5 mmHg increments.
Adaptive Inflation Choices are ON or OFF. If User
Configuration #3 is set to display
graphics, the choices are -l- or -O-.
Interval Setting Set the NIBP Interval Time. The
choices are: OFF (or ——), Cont.
(Continuous), 1, 2.5, 5, 10, 15,
20, 30, 60, 120, and 240 minutes.
Adult Alarm Set the default alarm limit values for
Limits an Adult size patient. See Section 1.3.5
for details on setting alarm limits.
Pediatric Alarm Set the default alarm limit values
Limits for a Pediatric size patient. See
Section 1.3.5 for details on setting
alarm limits.
Neonate Alarm See the default alarm limit values
Limits for an Neonate size patient. See
Section 1.3.5 for details on setting
alarm limits.
Alarm Volume Set the volume of an alarm signal.
The choices are: 1, 2, 3, 4 & 5. 5 is
the loudest.
SpO Volume Set the volume of the SpO
2
The choices are: Off (or ——), 1,
2, 3, 4 & 5. 5 is the loudest.
Continuous Print Choices are ON or OFF. If User
Configuration #3 is set to display
graphics, the choices are -l- or -O-.
Reset to Factory To change all of the User
Defaults Configuration items back to the
Factory Defaults, while in User
Config. #12, press and hold the
START NIBP key for 3 seconds.
Factory Default
3 minutes
3 minutes
180 mmHg
140 mmHg
100 mmHg
ON
OFF (or ——)
OFF, except SpO low
2
which is 86
OFF, except SpO low
2
which is 86
OFF, except SpO low
2
which is 86
4
beep. OFF
2
OFF
Accutorr Plus Service Manual
Chapter 1, Operation
