NIBP Circuit Board Assembly
Item Part Number
No.
66 0309-00-3572
67 0309-00-3653
68 0309-00-3654
69 0309-00-3831
70 0309-00-4751
71 0309-00-5112
72 0309-00-5903
73 0309-00-6042
74 0309-00-7500
75 0309-00-8660
76 0310-00-0100
77 0311-01-1501
78 0311-01-2502
79 0315-00-0102
80 0315-00-0103
81 0315-00-0104
82 0315-00-0202
83 0315-00-0221
84 0212-10-0608
85 0344-00-0223
86 0220-22-0632
87 0378-02-0004
88
89 0388-00-0584
90
91 0406-00-0762
92 0136-00-0295-06 CONNECTOR, Right Angle Socket,
93 0682-00-0072
94 0682-00-0086
Accutorr Plus Service Manual
Chapter 6 - Parts
Description
RESISTOR, Metal film, 1/8 W, 1%
35.7K
RESISTOR, Metal film, 1/8 W, 1%
365K
RESISTOR, Metal film, 1/8 W, 1%
3.65M
RESISTOR, Metal film, 1/8 W, 1%
3.83K
RESISTOR, Metal film, 1/8 W, 1%
4.75K
RESISTOR, Metal film, 1/8 W, 1%
51.1K
RESISTOR, Metal film, 1/8 W, 1%
590K
RESISTOR, Metal film, 1/8 W, 1%
60.4K
RESISTOR, Metal film, 1/8 W, 1%
750 Ohm
RESISTOR, Metal film, 1/8 W, 1%
866 Ohm
RESISTOR, Metal film, 1/4 W, 1%
10 Ohm
RESISTOR, Variable , 500 Ohm
RESISTOR, Variable, 5K
RESISTOR, Carbon film, 1/4 W,
5%, 1K
RESISTOR, Carbon film, 1/4 W,
5%, 10K
RESISTOR, Carbon film, 1/4 W,
5%, 100K
RESISTOR, Carbon film, 1/4 W,
5%, 2K
RESISTOR, Carbon film, 1/4 W,
5%, 220 Ohm
Screw, Nylon, Std
Fastener, Snap-in
Nut, Hex, Nylon, Std
Air Filter, 25 µm 1/8 barb
PCB, NIBP
Bracket, Sensors Mounting
6 Pin
TRANSDUCER, Blood pressure
sensor
TRANSDUCER, 7 PSIG with signal
conditioning
0670-00-0584-02
Reference
R19
R55
R51
R26
R8
R16, R24
R10, R18
R57
R25, R58
R29
R1
R1
R40
R28
R21, R34, R35
R2, R38, R41, R44, R53
R36
R6, R31, R32
N/A
N/A
N/A
N/A
PT1
PT2
Revised 12/20/00
6-27
