Datascope Accutorr Plus Service Manual page 188

NIBP Circuit Board Assembly
Item Part Number
No.
38 0283-04-0474
39 0283-05-0101
40 0283-05-0103
41 0283-05-0220
42 0283-05-0332
43 0285-00-0055
44 0285-15-1473
45 0290-02-3105
46 0290-11-0001
47
48 0307-00-0029
49 0307-01-0102
50 0309-00-1001
51 0309-00-1002
52 0309-00-1003
53 0309-00-1103
54 0309-00-1213
55 0309-00-1214
56 0309-00-1500
57 0309-00-1502
58 0309-00-1691
59 0309-00-1823
60 0309-00-2001
61 0309-00-2212
62 0309-00-2431
63 0309-00-3012
64 0309-00-3013
65 0309-00-3321
6-26
Revised 12/20/00
Description
CAPACITOR, 0.47µF 10%, 50V
Ceramic
CAPACITOR, 100pF 10%, 200V
Ceramic
CAPACITOR, 0.01µF 10%, 100V
Ceramic
CAPACITOR, 22pF 10%, 200V
Ceramic
CAPACITOR, 0.0033µF 10%, 100V
Ceramic
CAPACITOR, 0.47µF 5%, 63V
Poly.
CAPACITOR, 0.047µF 5%, 63V
Poly.
CAPACITOR, 1µF 10%, 35V,
Dipped Tantalum
CAPACITOR, 3300µF 20%, 16V,
Electrolytic
RESISTOR NETWORK, 14 PIN
DIP, 10K
RESISTOR NETWORK, 10 PIN
SIP, 1K
RESISTOR, Metal film, 1/8 W, 1% 1K R3, R7, R12, R15, R20
RESISTOR, Metal film, 1/8 W, 1%
10K
RESISTOR, Metal film, 1/8 W, 1%
100K
RESISTOR, Metal film, 1/8 W, 1%
110K
RESISTOR, Metal film, 1/8 W, 1%
121K
RESISTOR, Metal film, 1/8 W, 1%
1.21M
RESISTOR, Metal film, 1/8 W, 1%
150 Ohm
RESISTOR, Metal film, 1/8 W, 1%
15K
RESISTOR, Metal film, 1/8 W, 1%
1.69K
RESISTOR, Metal film, 1/8 W, 1%
182K
RESISTOR, Metal film, 1/8 W, 1%
2K
RESISTOR, Metal film, 1/8 W, 1%
22.1K
RESISTOR, Metal film, 1/8 W, 1%
2.43K
RESISTOR, Metal film, 1/8 W, 1%
30.1K
RESISTOR, Metal film, 1/8 W, 1%
301K
RESISTOR, Metal film, 1/8 W, 1%
3.32K
0670-00-0584-02
Reference
C7, C19, C23, C24, C48, C50
C9
C16, C26
C30
C15
C1, C2, C3, C5, C35
C36
C28
C27
RN1, RN2
RN3
R5, R14, R49
R43
R23
R9, R46, R50
R17, R39
R22
R56
R27
R48, R52
R47, R54
R13, R37, R45
R11
R30
R42
R33
Accutorr Plus Service Manual
Chapter 6 - Parts
