Power Sup ply, Lith ium Ion
Item Part Num ber De scrip tion
No.
46 Di ode ZNR 1.0W 5% SMD 3.9V
47 Di ode ZNR SMT 5.1V 5% SOT23
48 Di ode ZNR SMT 12.0V 5% SOT23
49 Di ode ZNR 1.0W 5% SMD 18.0V
50 Di ode ZNR SMT 18.0V 5% SOT23
51 Rect UFR 200V 1.0A MUR120 SMT
52 Rect Schtky SMT 30V 0.3A SOT23
53 Rect 1xSCH 45V 10A MBR1045
54 Rect 1xUFR 300V 8A BYT08P300
55 IC VR +15V 2% 0.5A 78M15 TO220
56 IC VR -15V 1% 0.5A 79M15 TO220
57 IC Volt De tec tor ICL7665CPA
58 IC VR SHUNT TL431 2.0% SOP-8
59 Opto-Coupler TSTR 4N35
60 Varistor 300VAC 80J
61 IC PWM 3844 SO-8
62 IC PWM 3843 SO-8
63 IC Batt Charger BQ2000 SOIC
64 Res F CF 1/4W 5% P 4.7 Ohm
65 Res F MF 1/4W 1% P 226.00K Ohm
66 Res F MO 2W 5% P 0.10 Ohm
67 Res F MO 2W 5% P 120.00K Ohm
68 Res F MO 2W 5% NP 33.00K Ohm
69 Therm is tor NTC 10.0 Ohm 1.7A
70 Res F MO 1W 5% NP 470.00 Ohm
71 Res F MO 1W 5% P
72 Res F MO 1/4W 5% P 22.00 Ohm
73 Res F CF 1/4W 5% NP 47.0 Ohm
74 Res SMT 1.00KOhm 1% 1206
75 Res SMT 150.00KOhm 1% 1206
76 Res SMT 200.00KOhm 1% 1206
77 Res SMT 221.00 Ohm 1% 1206
78 Res SMT 27.40 Ohm 1% 1206
79 Res SMT 365.00KOhm 1% 1206
80 Res SMT 681.00KOhm 1% 1206
81 Res F SM 1/3W 5%
82 Res F SM 1/4W 5%
83 Res SMT 4.7 Ohm 5% 1206
84 Res F SM 1/4W .25% 1.24K Ohm
85 Res SMT 1.00K Ohm 1% 0805
86 Res SMT 1.00K Ohm 1% 0805
87 Res SMT 10.70K Ohm 1% 0805
88 Res SMT 113.00K Ohm 1% 0805
89 Res SMT 124.00 Ohm 1% 0805
90 Res SMT 13.70K Ohm 1% 0805
6-40
Ref er ence
CR14
CR20
CR16,19
CR4
CR8
CR3,6,7,21
CR12,15,22,23,24
CR10
CR11
U5
U3
U8
U4
U2
M1
U1
U6,9
U7
R18
R4,21
R22
R2
R16
RT1
R46,59
0.47 Ohm R1
R14
R28
R69,70,71,75
R57
R25,74
R32,83
R36,54
R30,50,62,87
R48,79
1.0K Ohm R65,67,68
47.0 Ohm R84
R53
R9,19,39,40,52
R5,13,31,34,43,78,82,85,88
R95
R10,23,45,58,63,76,93
R17,47
R90
R7
0014-00-0225
