Datascope Accutorr Plus Service Manual page 16

1. NIBP Systolic Display
Displays the systolic blood pressure data from NIBP measurements. It is also used to
display NIBP error codes and systolic alarm limits.
2. NIBP Diastolic Display
Displays the diastolic blood pressure data from NIBP measurements. It is also used
to display diastolic alarm limits.
3. NIBP MAP Display
Displays the mean arterial pressure (MAP) information from NIBP measurements.
During a measurement, it will display the cuff pressure. It is also used to display the
MAP alarm limits and the inflation pressure when selecting the initial inflation
pressure.
4. Pulse Rate Display
Displays the pulse rate information from either the NIBP measurement or the SpO2
reading (Accutorr Plus model with SpO
limits.
5. NIBP/SpO
When the pulse rate displayed is based on an NIBP measurement, then NIBP is illu-
minated. When the pulse rate displayed is based on an SpO
(Accutorr Plus model with SpO
6. SpO
Displays the %SpO
the %SpO
7. Liquid Crystal Display (LCD) (Accutorr Plus models with Trend Screen)
The Liquid Crystal Display (LCD) is used to display previous measurements (trend
list) for the selected patient, or a menu that controls the beep volume and alarm volume.
8. Menu Key (Accutorr Plus models with Trend Screen)
This key is used to toggle between the trend list screen and the menu screen in the
LCD. When the back light in the LCD is off, pressing this key turns it on. This key
is also used to adjust the LCD contrast. Press and hold the key for two beeps to enter
the adjustment mode. Use the Arrow keys (9 and 10) to change the contrast.
9. LCD Up Arrow Key (Accutorr Plus models with Trend Screen)
This key is used to scroll the trend data so that more recent measurements are
displayed in the LCD. When the back light in the LCD is off, pressing this key turns
it on. This key is also used to adjust the LCD contrast when in the adjustment mode.
Use the Menu key (8) to enter the adjustment mode.
10. LCD Down Arrow Key (Accutorr Plus models with Trend Screen)
This key is used to scroll the trend data so that older measurements are displayed in
the LCD. When the back light in the LCD is off, pressing this key turns it on. This
key is also used to adjust the LCD contrast when in the adjustment mode. Use the
Menu key (8) to enter the adjustment mode.
1-8
Pulse Rate Indicator
2
2
Display (Accutorr Plus model with SpO
2
measurement information. This area is also used to display
2
alarm limits.
2
). It is also used to display pulse rate alarm
2
2
), then SpO is illuminated.
2
)
2
Accutorr Plus Service Manual
measurement
Chapter 1, Operation
