Datascope Accutorr Plus Service Manual page 185

Recorder Board Assembly
Item Part Number
No.
1 0108-00-0058
2 0108-00-0078
3 0136-00-0201
4 0136-00-0226
5 0136-57-0044
6 0136-92-0005
7 0151-00-0013
8 0151-00-0035
9 0151-00-0133
10 0153-00-0014
11 0153-00-0086
12 0155-00-0081
13 0155-00-0772-02 Quad 2 input NAND w/Schmitt
14 0155-00-0868-01 IC, LB1257, 8 channel driver
15
16
17 0155-90-0292-02 IC, Programmed, Printer Control
18 0161-00-0015
19 0211-13-0206-00 SCREW, M2x0.4, 6mm long, pan
20 0283-04-0104
21 0283-05-0102
22 0283-10-1821
23 0290-00-0122
24 0290-07-2223
25 0307-06-2102
26 0311-01-1503
27 0315-00-0101
28 0315-00-0102
29 0315-00-0103
30 0315-00-0104
31 0315-00-0123
32 0315-00-0164
Accutorr Plus Service Manual
Chapter 6 - Parts
Description
Bead, Leaded Ferrite
INDUCTOR FIXED, 150 µH, power
CONNECTOR PC, Test point
CONNECTOR PC, Receptacle, 9
pin flex cable
SOCKET, PLCC, 44 pin
CONNECTOR PC, Header, straight
locking and polarized, 5 pin
TRANSISTOR, PNP, 2N3906
TRANSISTOR, NPN, 2N3904
TRANSISTOR, 2N6715, NPN,
medium power
DIODE, PN Switching
1N4148/1N914
DIODE, PN, Rectifier, 1N5806
IC, Hex Inverter, CMOS, 4069
trigger input, 74HC132
(LB1257)
RECORDER, Thermal Printer
Mechanism
head, ss
CAPACITOR, Ceramic, 0.1uF,
100V, 10%
CAPACITOR, Ceramic, X7R,
1000pF, 200V, 10%
CAPACITOR, Ceramic,Ultra-Stable,
820pF, 100V, 5%
CAPACITOR ELECTROLYTIC,
Aluminum, 3300 µF, 10 V radial
CAPACITOR, Electrolytic, Aluminum,
22uF, 16V, 20%
RESISTOR NETWORK, 10 pin SIP,
1k
RESISTOR, Variable 1/2W, 50k,
horizontal mount
RESISTOR, FIXED, Carbon film,
1/4 W, 100, 5%
RESISTOR, FIXED, Carbon film,
1/4 W, 1k, 5%
RESISTOR, FIXED, Carbon film,
1/4 W, 10k, 5%
RESISTOR, FIXED, Carbon film,
1/4 W, 100k, 5%
RESISTOR, FIXED, Carbon film,
1/4 W, 12k, 5%
RESISTOR, FIXED, Carbon film,
1/4 W, 160k, 5%
0670-00-0583
Reference
L1
L2
TP1
J3
XU1
J2
Q3
Q1, Q2, Q4, Q5
Q6, Q7
D1, D2
D3
U3
U4
U2
U1
C1, C2, C7, C8, C9, C10, C11, C12, C13, C14, C15
C17
C16
C4, C5, C6
C3
RN1
R1
R8, R9, R22, R23, R24, R25
R12, R14, R16
R7, R13, R15, R18
R6, R10, R11
R3
R2
