CPU/LED Board
Item Part Number
No.
61 0289-00-3476
62 0289-01-2106
63 0289-01-2226
64 0289-01-4226
65 0289-01-4476
66 0289-01-5107
67 0307-20-2202
68 0307-21-1000
69 0324-00-0100
70 0324-00-0101
71 0324-00-0103
72 0324-00-0104
73 0324-00-0122
74 0324-00-0330
75 0326-00-0101
76 0326-01-1000
77 0326-01-1001
78 0326-01-1002
79 0326-01-1003
80 0326-01-1004
81 0326-01-2001
82 0326-01-2003
83 0326-01-2211
84 0326-01-2492
85 0326-01-2741
86 0326-01-3321
87 0326-01-3323
Accutorr Plus Service Manual
Chapter 6 - Parts
Description
CAPACITOR SMD TANTALUM
20%, 47UF
CAPACITOR SMD
ELECTROLYTIC 20%, 10UF
CAPACITOR SMD
ELECTROLYTIC 20%, 22UF
CAPACITOR SMD
ELECTROLYTIC 20%, 22UF
CAPACITOR SMD
ELECTROLYTIC 20%, 47UF
CAPACITOR SMD
ELECTROLYTIC 20%, 100UF
RESISTOR SPECIAL NETWORK
15 ELEMENT BUSSED 1%, 22.0K
RESISTOR NETWORK 8
ELEMENT ISOLATED , 100 ohm
RESISTOR SMD THICK FILM
1/4W 5%, 10
RESISTOR SMD THICK FILM
1/4W 5%, 100
RESISTOR SMD THICK FILM
1/4W 5%, 10K
RESISTOR SMD THICK FILM
1/4W 5%, 100K
RESISTOR SMD THICK FILM
1/4W 5%, 1.2K
RESISTOR SMD THICK FILM
1/4W 5%, 33
RESISTOR SMD THICK FILM
1/10W 5%, 100
RESISTOR SMD THICK FILM
1/10W 1%, 100
RESISTOR SMD THICK FILM
1/10W 1%, 1K
RESISTOR SMD THICK FILM
1/10W 1%, 10K
RESISTOR SMD THICK FILM
1/10W 1%, 100K
RESISTOR SMD THICK FILM
1/10W 1%, 1MEG
RESISTOR SMD THICK FILM
1/10W 1%, 2K
RESISTOR SMD THICK FILM
1/10W 1%, 200K
RESISTOR SMD THICK FILM
1/10W 1%, 2.21K
RESISTOR SMD THICK FILM
1/10W 1%, 24.9K
RESISTOR SMD THICK FILM
1/10W 1%, 2.74K
RESISTOR SMD THICK FILM
1/10W 1%, 3.32K
RESISTOR SMD THICK FILM
1/10W 1%, 332K
0670-00-0650-03/04
Reference
C7-C9
C63
C61,C62
C11,C65,C80
C5,C6,C10,C81
C66
RN1-RN4
RN6,RN8,RN10
R28-R30
R14,R23,R24
R1
R44
R10
R32
R50
R20,R35,R43,R46,R47,R49,R52,R53,R55-R71,R73-
R75,R77,R79-R89
R4-R6,R17,R25,R37-R40,R54
R2,R7,R9,R13,R15,R18,R19,R21,R22,R27,R33,R34
,R42,R78
R11,R48,R72
R3,R90
R31,R36
R12
R26
R45
R16
R8
Revised 12/20/00
6-33
