Datascope Accutorr Plus Service Manual page 201

Power Sup ply, Lith ium Ion
Item Part Num ber De scrip tion
No.
1 PCB-BARE,SMT D/S,MSP1698,PN1X
2 IN DUC TOR,GPx80'S
3 CHOKE,NOISE
4 XFMR,CUR RENT,EP7
5 XFMR-EMI IN DUC TOR
6 OUT PUT STOR AGE CHOKE
7 XFMR-DC/DC,MSP1698
8 XFMR-POWER,MSP1698
9 IN DUC TOR,MSP1698
10 PRI FET BRKT W/HDWR,MSP1510
11 L BRKT W/HDWR & S/S,MSP1698
12 Cap DK R ACY 250V 220PF
13 Cap DK R X7R 1KV 125C 10000PF
14 Cap AL R 105C 25V 100.00MF S
15 Cap AL R 105C 25V 47.00MF S
16 Cap AL R 105C 50V 47.00MF S
17 Cap AL Lo-Z 105C 35V 390MF
18 Cap AL Lo-Z 105C 35V 220MF
19 Cap AL R 105C 400V 82MF 22X30
20 Cap FI R ACX 275V 0.100MF
21 Cap Tant SMT 10.0uF 20V 3528
22 Cap Tant SMT 1.0uF 16V 3612
23 Cap SMT 10.0nF 10% 100V 0805
24 Cap SMT 0.1uF 10% 25V 0805
25 Cap SMT 1.0nF 10% 100V 0805
26 Cap SMT 47.0nF 10% 50V 0805
27 Cap SMT 1.0nF 5% 50V 1206
28 Cap SMT 4.7pF 10% 50V 0805
29 Cap SMT 2.2nF 10% 200V 1206
30 Cap SMT 470.0pF 10% 200V 1206
31 Cap SMT 4.7nF 10% 200V 1206
32 Cap SMT 0.33uF 20% 50V 1210
33 Tstr P 60V 0.6A 2907A
34 Tstr FET N 600V 6.0A TO-220
35 Tstr FET P 45V 0.18A BS250
36 Tstr N 40V 0.6A MBT2222A
37 Tstr P 60V 0.6A MBT2907A
38 Tstr FET N 60V 20.0A D-PAK
39 Tstr FET P 30V 19.0A D-PAK
40 Tstr FET N 60V .12A SOT23
41 Tstr FET P 60V 12.0A TO-220
42 Rect UFR 1000V 1.0A MUR1100 P
43 Rect Bridge 600V 2A Small
44 Rect SCH 40V 3.0A SMD
45 Rect 2 X SCH 40V 3.0A SMD
Accutorr Plus Service Manual
Chapter 6 - Parts
0014-00-0225
Ref er ence
PCB
T1
L1,3
T4,5
T6
L2
T3
T2
L4
FN1
FN1
C5,6
C10
C43
C18,21
C2
C16,19,42,45
C11,12,34
C7
C1
C32,35,58
C23,47,48,53
C4,13,20,27,28,29,49
C24,30,33,36,44,50,55
C8,25,38,51,52
C31
C3,26,37,41
C57
C39,56
C9,40,59
C54
C15,22,46
Q6
Q1
Q2
Q7,8,9,10,14,17,20
Q4,12,13,15,18,19
Q11
Q3
Q16
Q5
CR20
CR1
CR5,13,17
CR9
6-39
