11.3 Standard Setting Functions

11.3.1 Standard Setting Functions
Table 11.5 Standard Setting Functions
Function
Burnout
Tag Number
Reference Junction
Compensation
Copy Function
Input Offset
Zone Recording
(Track Recording)
Partial
Compression/Expansion
Decade Recording Indication
Alarm Print
Alarm Recovery Print
Record Start/end Print
Computation
Inter-channel Computation
Alarm Hysteresis Width
Digital Filter

11.4 Optional Functions

11.4.1 Remote Function of DI

Chart Feed Start/Stop
Changing Chart Speed
Comment Print（Sync./Async.）
Manual Print（Sync./Async.）
Date and Time Print（Sync./Async.）

11.4.2 Alarm Board

3 relays

11.4.3 Communication Unit

RS-232C(Standard)
RS-485(Option)
To deflect over toward 100% with disconnecting input. Specifies the
every channel's burnout. (DC voltage of ±50mV max., TC input )
Sets a tag number by 5 figures every channel. (Prints at a logging print)
Specifies an inside/outside of the reference junction compensation.
Copies a channel setting up.
Sets the input offset every channel.
Specifies a recording area every channel to separate into Tracks.
Records Partial Compression/Expansion to 1-crease line every
channel.
Records and indicates by 5 decades. It is 2 figures that the effective
number to indicate and print.
Prints Occurrence time, Occurrence channel, Setting No. and Alarm
type in purple at occurring an alarm.
Prints Recovery time, Recovery channel, Setting No. and Alarm type in
purple at recovering an alarm.
Prints time and comment ("Start" or "End") when record beginning or
end.
Computes Square root.
Computes Sum, Difference and Average computation.
Sets an alarm hysteresis width 0% FS or 0.5% FS.
Records the first order lag with the filtering Process variable.
Function
―128―
Description
Description
Starts with tuning to ON. Stops with tuning to OFF.
Changes 1st with turning to ON and 2nd with OFF.
Prints Comment with turning to ON.
Prints Manual Print with turning to ON.
Prints Date and Time with turning to ON.
