10.1 Troubleshooting

10.1.1 Trouble Items

Trouble
Does not work at all
Big error
Recording
error
Chart paper
feed error

10.1.2 When the Recorder Does not Work at All

Flow chart 1
Does not work at all
Power turned on?
Power terminal
connected
properly?
Power supplied
properly?
Contact our dealer where you
purchased the instrument, or our
sales representative.
Pen recording deflected
Nothing is printed at all
Faint printing
Chart paper is not fed at all
Improper feed
Inaccurate feed rate
ＮＯ
ＹＥＳ
ＮＯ
ＹＥＳ
ＮＯ
ＹＥＳ
10． TROUBLESHOOTING
Flow chart 1 (Page 112)
Flow chart 2 (Page 113)
Flow chart 3 (Page 113)
Flow chart 4 (Page 114)
Flow chart 5 (Page 114)
Flow chart 6 (Page 115)
Flow chart 7 (Page 115)
Contact our dealer where you
purchased the instrument, or our
sales representative.
Turn on the power
Connect properly (See 4.1 on
Page 16)
Supply properly
―112―
Remedy
85 to 264VAC
45 to 65Hz
