2.2 Display Screen and Operation Keys
2.2.1 Display Screen
The following describes the display screen. Since the channel numbers and data are indicated by a
7-segment LED, alphabets are symbolized to represent them.
For the LED display, see " Symbolized Alphabets for Display" at [Reference] below.
Channel No. Display
Indicates a channel
number in orange.
The "RUN" lamp (orange) is illuminated when
recording. The "ALM" lamp (red) is illuminated when
the alarm is being activated.
lamp goes out and
［Reference］ Symbolized Alphabets for Display
Display
Alphabet
Display
Alphabet
Alarm Type Display
Indicates an alarm type in red.
"H" is illuminated when the alarm is High.
And "L" is illuminated when the alarm is
Low. Neither of them is illuminated when
there is no alarm.
CH.No
H
L
RUN
RUN
ＡＬＭ
Status Display
denotes that the
denotes that it is illuminated.
Fig. 2.2 Display
A
B
C
D
M
N
O
P
DATA
▲
ESC
MENU
PRINT
Use these keys for setting and
other operations.
ｈ
E
F
G
H
Q
R
S
T
U
―11―
Data Display
Indicates the process
variable, time, setting
screen, etc. in orange.
FEED
ENT
Operation Keys
I
J
K
L
V
W
X
Y
Z
HXPRM10mnCT002E
ｌ
