① RTD input
+
B
B
B
CAUTION
① Attach the shunt resistor to the input terminal block of the instrument.
② Input accuracy is effected with the shunt resistor. Use the following recommended resistor.
Resistance：250Ω Rated power：1/4W Tolerance：±0.1% max.
Temperature coefficient：±50ppm max.
-
B
A
A
Fig. 4.5 Input Wiring ( RTD, mA )
―20―
② mA input
+
-
B
B
A
Shunt registor
＋
－
HXPRM10mnCT002E
