11.2 Standard Setting Specifications

11.2.1 Measurement Range

The arbitrary setup is possible by the operation key.
A digital accuracy rating is as Table11.2 at Reference operating conditions. It is shown below.
Reference operating conditions ：Temperature
The performance in the state where nothing is vibration and a shock.
Terminal block reference junction compensation accuracy is not included in the digital accuracy rating.
It is shown below.
Terminal block reference junction compensation accuracy.
◆ B､R､S､PR40-20､Au-Fe
◆ K､E､J､T､C､N､PLⅡ､U､L
Table 11.2 Measurement Range
Type RANGE Measurement range
B
R1
Humidity
Power source voltage
Electric wave frequency
Warming up time
:±1℃
:±0.5℃
-10 to 10mV ±(0.2% of rdg + 3digits)
0 to 20mV ±(0.2% of rdg + 3digits)
0 to 50mV ±(0.2% of rdg + 2digits)
-200 to 200mV ±(0.2% of rdg + 3digits)
-1 to 1V ±(0.1% of rdg + 3digits)
0 to 5V ±(0.2% of rdg + 2digits)
-10 to 10V ±(0.3% of rdg + 3digits)
4 to 20mA ±(0.2% of rdg + 2digits)
±(0.15% of rdg + 1℃)
400 to 600℃, ±2℃
0.0 to 1820.0℃
An accuracy is not compensated
within a range of 0 to less than
400℃
±(0.15% of rdg + 1.8ﾟF)
752 to 1112℃, ±3.6ﾟF
32.0 to 3308.0ﾟF
An accuracy is not compensated
within a range of 32 to less than
752ﾟF
±(0.15% of rdg + 1℃)
※0 to 100℃, ±3.7℃
0.0 to 1760.0℃
100 to 300℃, ±1.5℃
±(0.15% of rdg + 1.8ﾟF)
※32 to 212℃, ±6.7ﾟF
32.0 to 3200.0ﾟF
212 to 572ﾟF, ±2.7ﾟF
―121―
; 23 ±2℃
; 55 ±10%RH
; 85 to 264V AC
; 50/60%Hz ±1%
; 30 minutes min.
Measurement
Digital
Accuracy
resolution
0.1℃/0.18ﾟF
Analog
Max.
Accuracy
10μV
10μV
10μV
100μV
1mV
1mV
10mV
0.01mA
Digital accuracy
±(0.3% of span)
HXPRM10mnCT002E
