(7) Leveling the Ribbon Cassette
Prior to the pulling out the ribbon cassette, level it.
Ribbon
Cassette
Fig. 5.21 Leveling the Ribbon Cassette (Ribbon Cassette Sectional View)
(8) Pulling out the Ribbon Cassette
Pull out the ribbon cassette horizontally. If the gear of the ribbon cassette touches the printer, move
the printer further to the right.
(9) Unslacking the Ink Ribbon
Set the new ink ribbon. Turn the gear in the arrow direction to unslack the ink ribbon.
Turn the gear in the
arrow direction.
Ink Ribbon
Fig. 5.22 Unslacking the Ribbon
―36―
Lower the hook of the
ribbon cassette.
Main Shaft
Hook
Gear
