Scaling - Toho Electronics TRM-10C Instruction Manual

Scaling ）
(3)
Changes the input of VOLT, TC and RTD into a quantity.
Setting the unit is possible.(See 7.1.3 on page 67.)
Example) When setting the voltage of 0 to 40 mV and scale of 000.00 to 100.00 for Channel 1
Display
（Zero input value）
［Note］
When input TC and RTD, set the Zero input value equal to the Zero-side scale value.
But, set a decimal point position to the standard position. (＊1:next page)
（Span input value）
［Note］
When input TC and RTD, set the Span input value equal to the Span-side scale value.
But, set a decimal point position to the standard position. (＊2:next page)
Operation Keys
ESC
Hold down the MENU key for 3 seconds or more to
3 sec
MENU
enter the setup mode. Use the △ key to indicate "
PRINT ENT
Use the △ key to select the channel you want to set.
PRINT
ENT
Press the "ENT" key.
Use the △ key to select "
PRINT
ENT
Press the "ENT" key.
Use the △ key to select "
PRINT ENT
Press the "ENT" key.
Use the △ key to select a range(50 mV).
PRINT ENT
Press the "ENT" key.
Use the △ key to select a numeral.
PRINT FEED
Use the
ENT
Use the △ key to select a numeral.
PRINT FEED
Use the
ENT
―57―
Description
". Press the "ENT" key.
".
key to shift a digit. Press the "ENT" key.
key to shift a digit. Press the "ENT" key.
