(4) Taking out the Chart Holder
Put your fingers onto the levers at both sides of the chart holder and pull it out to this side.
Lever
(5) Opening the Chart Cover and Chart Guide
Open the chart guide and the chart cover outwardly.
Chart Guide
(Transparent)
Open in the arrow
direction.
Fig. 5.6 Opening the Chart Cover and Chart Guide
Fig. 5.5 Taking out the Chart Holder
―27―
Pull out the chart
holder to this side.
Chart Cover (Black)
Open in the arrow direction.
HXPRM10mnCT002E
